Ford Fiesta Mk8 bucket seat guide
Mk8 generation, including ST; fitting-kit start dates vary
For the Mk8-generation Fiesta and ST, the vehicle fitting choices here come from Cobra and SW Motorsport. Choose the lower frame with the exact seat and upper mounting parts in mind, checking the fixing positions, installed height and cabin clearance together.
The shop lists Cobra from 2018 onwards and the SW single and pair bases from 2019 onwards; Cobra’s manufacturer application table starts the Mk8 in 2017, so an early build needs its exact application confirmed before ordering.
Keep this car separate from the earlier Fiesta generation, including ST180 and ST200. Send Garreth the build year and body style if the Mk7/Mk8 naming leaves you unsure which listing applies. Cameron can then check the seat, physical seating side and complete mounting arrangement.
- Two fitting brands: Cobra and SW Motorsport. Their shop start dates differ, so confirm the exact vehicle application, especially for a 2017 or 2018 car.
- SW single, pair and ST listings repeat driver SW-SM-0018 and passenger SW-SM-0082 supplier references; they are order options for the same stated base family.
- Cobra has RHD driver, RHD passenger and pair choices. Match the physical side and seat-specific FRM-15 assembly to the supplied kit.
- Base width alone does not establish seat compatibility: supports, runner fixing positions, hardware and the complete installed height each need checking.
- The full SW cage uses weld-in foot plates and passes through the dashboard; confirm body, roof, installation and event requirements before ordering.
Mounting
A lower frame attaches to the Fiesta floor, while runners or side supports create the connection to the chosen seat; confirm each connection and the parts supplied with the order. Cameron can check whether the resulting position leaves the driver enough headroom and clearance to the console, door and controls.
Use the year and exact vehicle application shown for the selected frame; the general Mk8 heading does not widen a supplier’s start date.
SW Motorsport single-side base
The SW single-base listing is for the RHD Mk8 from 2019 onwards, including ST, with one base per selected seating position. Its description specifies SW-SM-0018 for the RHD driver and SW-SM-0082 for the RHD passenger.
Side supports, sliders, mounting bolts and harness eyebolts are separate. The optional supports have 8 or 10 mm seat-bolt choices; match those to the actual shell. The 345 mm width attribute supplies only one dimension, so confirm the complete upper fixing arrangement before pairing a seat or runner with the base.
-
From £134.89 Incl. VATFrom £112.41 Excl. VATPayPal CreditSelect options This product has multiple variants. The options may be chosen on the product page
SW Motorsport driver and passenger pair
The two-base listing supplies the stated driver and passenger bases in one order. It retains the shop’s 2019-onwards application and the same SW-SM-0018/0082 references. Its optional extras are described for both seats; ask Garreth to check the quantities and exact supports, runners and fixings included in your chosen order.
SW Motorsport ST listing
The ST Mk8 listing repeats SW-SM-0018 and SW-SM-0082, with RHD driver and passenger choices to match against your ST build and seating side. Its ST name alone does not extend the 2019-onwards single-base application to every early Mk8 car.
-
From £134.89 Incl. VATFrom £112.41 Excl. VATPayPal CreditJust inSelect options This product has multiple variants. The options may be chosen on the product page
Cobra Mk8 frame and FRM-15 assembly
Cobra’s maker table identifies the Mk8 with SU-FOR-FIE-03L and SU-FOR-FIE-03R and the FRM-15 assembly. The shop product has RHD driver, RHD passenger and pair selections. Its passenger variant currently has an -LHD SKU suffix, so use the displayed seating-position choice and confirm physical left or right when checking the order.
Cobra publishes 292 and 405 mm FRM-15 configurations with Premium runners and different handle widths. Both drawings show a seat-dependent belt bracket and a spacer arrangement, with the passenger side requiring the corresponding reversed layout and handed bracket. Ask Garreth to confirm the correct seat-specific assembly and current contents.
The shop frame attribute says 291 x 330 mm, while Cobra describes its base-mounted seat patterns as 292 or 405 x 330 mm. Resolve the exact configuration before ordering. The 292 mm drawing also lists its base component as FRM-12 despite its FRM-15 title, so have Cobra confirm that supplied part designation; the drawing label does not establish interchange with the earlier Fiesta frame.
-
From £255.00 Incl. VATFrom £212.50 Excl. VATPayPal CreditKlarna ReadyJust inSelect options This product has multiple variants. The options may be chosen on the product page
Sliding runners
Cobra Premium runners SUBFR07EL belong with the specified Cobra seat assembly and handle configuration. Endurance and Sparco 0049306 runners are separate options to check against the chosen SW base and seat. Compare both fixing interfaces, lock operation and total height before ordering.
For a competition installation, follow Cobra’s intended-use guidance on side mounts and runners as well as the event rules; its mounting page specifies a direct side-mount arrangement without runners for competition use.
-
From £84.00 Incl. VATFrom £70.00 Excl. VATPayPal CreditSelect options This product has multiple variants. The options may be chosen on the product page
Side supports
Sparco steel supports are an option for a compatible side-mounted shell and lower assembly, subject to shell width, fixing positions and hardware. Cobra Nogaro supports SUBFR31 are the Nogaro-specific choice. Cameron can check the complete support arrangement against the seat and required driving position.
Competition bucket seats
Sparco Sprint and Cobra Monaco Pro both list base and side mounting, but their base patterns differ: Sprint is 345 x 271 mm and Monaco Pro is 292 x 330 mm. Choose the mounting method for the actual supplied seat. A matching brand name or one shared dimension does not establish the complete installation.
OMP Champ-R and ARS-R, Mirco RTS-2 3D and RS2 3D, Sabelt GT3 and Sparco Evo L QRT are the side-mounted shell choices here. Match supports to the shell and lower assembly, then measure shoulder room and the seat’s clearance at the required driving position. A wider shell needs a specific cabin check.
Confirm the supplied seat’s approval label and event requirements separately from the frame, runners and vehicle installation.
-
From £252.00 Incl. VATFrom £210.00 Excl. VATPayPal CreditSelect options This product has multiple variants. The options may be chosen on the product page
-
From £282.00 Incl. VATFrom £235.00 Excl. VATPayPal CreditKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
-
From £400.80 Incl. VATFrom £334.00 Excl. VATPayPal Credit250+ coloursKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
-
From £425.40 Incl. VATFrom £354.50 Excl. VATPayPal Credit250+ coloursKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
Reclining sport seats
The Sparco R100 Vinyl, R100 Martini, R500 Fabric, R500 Sky and GT listings have a 345 x 271 mm base pattern. Check the selected lower base and runner interfaces, allowing room for backrest movement and clearance at the door and console.
Auto Style BS5 is listed at 345 x 280 mm, OMP RTS at 345 x 270 mm and Cobra Misano Anniversary Spec 2 at 291 x 330 mm. Those figures differ from the common Sparco pattern, so have Garreth confirm the exact seat, supplied runner contents and complete fixing arrangement before ordering.
OMP RTS is the recliner; the Mirco RTS-2 3D above is a separate fixed-back product.
-
From £282.00 Incl. VATFrom £235.00 Excl. VATPayPal CreditKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
-
£562.10Original price was: £562.10.£505.90Current price is: £505.90. Incl. VAT£468.42Original price was: £468.42.£421.58Current price is: £421.58. Excl. VATPayPal CreditKlarna ReadyAdd to basket -
From £461.00 Incl. VATFrom £384.17 Excl. VATPayPal CreditKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
Roll cage
SW’s Mk8 full bolt-in cage uses weld-in foot plates and passes through the dashboard, which needs cutting and trimming. Plan the installation with the cage maker before choosing it for the car. The current shop description also excludes factory-fitted sliding sunroofs, so confirm the precise body and roof application.
SW describes CDS tube dimensions and material in relation to Motorsport UK requirements; this does not establish approval for every championship or fitted car. Confirm the required specification, installation and current event rules with the maker before ordering.
-
From £1,344.00 Incl. VATFrom £1,120.00 Excl. VATPayPal CreditMade to orderKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
Harnesses
Assess the TRS Clubman, TRS Magnum, Takata Drift II and Drift III, and Schroth Profi 3×2 with the exact seat and proposed anchorage arrangement. Strap count alone does not establish that an original belt point, harness bar or cage tube is suitable. Follow the selected belt maker’s instructions for anchor strength, belt angles and attachment hardware.
Cameron can help check the intended belt route through the seat and around the cabin. Confirm the belt’s current approval and event requirements, together with the lap, shoulder and any crotch-strap attachments. A suitable cage and a suitable harness installation are separate checks.
-
From £96.00 Incl. VATFrom £80.00 Excl. VATPayPal CreditAmazing valueSelect options This product has multiple variants. The options may be chosen on the product page
-
From £120.00 Incl. VATFrom £100.00 Excl. VATPayPal CreditAmazing valueSelect options This product has multiple variants. The options may be chosen on the product page
-
From £246.00 Incl. VATFrom £205.00 Excl. VATPayPal CreditAmazing valueSelect options This product has multiple variants. The options may be chosen on the product page
-
From £274.80 Incl. VATFrom £229.00 Excl. VATPayPal CreditSelect options This product has multiple variants. The options may be chosen on the product page
-
From £294.00 Incl. VATFrom £245.00 Excl. VATPayPal CreditAmazing valueSelect options This product has multiple variants. The options may be chosen on the product page
-
From £324.00 Incl. VATFrom £270.00 Excl. VATPayPal CreditKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
-
From £444.01 Incl. VATFrom £370.01 Excl. VATPayPal CreditKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
What fits
Compare the complete fixing pattern, exact vehicle application and supplied parts before choosing a mounting route.
| Route or seat | Interface or application | Contents | Check before ordering |
|---|---|---|---|
| SW single /ST Mk8 | SW-SM-0018 driver /0082 passenger | One base per selected side | Shop 2019-onwards scope; supports/sliders/fixings separate |
| SW pair | One driver and one passenger base | Optional extras described for both seats | Confirm quantity and exact upper parts |
| Cobra Mk8 | SU-FOR-FIE-03L/R;FRM-15 | RHD driver/passenger/pair choices | Shop 2018 start vs maker 2017; exact kit needs checking |
| Cobra seat-specific assembly | 292 or 405 x 330 mm maker seat patterns | Premium runners,appropriate handle and belt brackets | Shop 291 x 330; 292 drawing has base-label conflict |
| Side-mounted shells | Supports matched to exact shell | Lower base and hardware checked together | Cabin width,headroom,controls and belt openings |
| Sparco Sprint /Cobra Monaco Pro | 345 x 271 / 292 x 330 mm base patterns | Both listings describe base and side mounting | Different base patterns;choose actual mounting method |
| Sparco R100 /R500 /GT | 345 x 271 mm shop base pattern | Confirm selected rails and lower connection | Backrest travel and full assembly height |
| Auto Style BS5 /OMP RTS | 345 x 280 / 345 x 270 mm shop base patterns | Exact supplied seat and rails | Neither figure equals 345 x 271 mm |
| Cobra Misano Anniversary Spec2 | 291 x 330 mm shop base pattern | Exact Cobra seat-specific assembly | Confirm maker pattern and supplied parts |
| SW full Mk8 cage | Weld-in foot plates;through-dashboard layout | Body/roof and exact event specification | Shop excludes factory sliding sunroofs;installation required |
Manufacturer references: Cobra vehicle and frame reference, FRM-15 narrow drawing, FRM-15 wide drawing, Cobra mounting guidance, SW Mk8 lower base and SW full Mk8 cage.
Common questions
Which Mk8 years do these frames cover?
The shop lists Cobra from 2018 and SW single and pair bases from 2019, while Cobra's maker table starts the Mk8 in 2017; confirm the exact vehicle application before ordering, especially for an early build.
Can I use an older ST180 or ST200 frame?
Keep the earlier Fiesta generation separate and choose a supplier application specifically confirmed for the Mk8 car.
Which SW base is the RHD driver side?
The current descriptions identify SW-SM-0018 as RHD driver and SW-SM-0082 as RHD passenger; select the physical side required for your car.
Does the single SW listing supply both sides?
One single-base order covers one seating position; use the two-base listing if you need the stated driver and passenger bases together.
What does the SW pair order include?
Its description supplies one driver and one passenger base. Side supports, sliders and installation hardware are separate unless chosen with the order. Confirm the quantities of optional extras for both seats.
Is the ST Mk8 listing another supplier base design?
Its shop description repeats SW-SM-0018 and SW-SM-0082; confirm the exact build and side, with the shop start-date limits still applying.
Does the SW 345 mm width prove a seat will bolt on?
It gives only one dimension, so compare the complete seat or runner pattern, support layout and hardware before ordering.
Which SW side-support bolt option should I select?
Match the optional 8 or 10 mm support choice to the actual seat shell's specified bolts and complete lower assembly.
Why is Cobra's passenger SKU labelled LHD?
The current -LHD variant is labelled RHD passenger in the shop; select the displayed seating position and confirm the physical side against the supplied Cobra kit.
Which Cobra application belongs to the Mk8?
Cobra identifies SU-FOR-FIE-03L/R and FRM-15 for the Mk8; match the seat-specific configuration and exact supplied kit to that application.
Are the Cobra 291 and 292 mm figures interchangeable?
The shop frame attribute says 291 x 330 mm and the maker describes 292 or 405 x 330 mm seat patterns; resolve the actual configuration and runner arrangement before ordering.
Why does the narrow Cobra drawing list FRM-12?
The 292 mm drawing has an FRM-15 title but an FRM-12 base-component label, so confirm the supplied designation with Cobra; that label alone does not establish interchange with an earlier Fiesta frame.
Will a lower base guarantee more headroom?
Measure the whole seat, frame, supports and any runners at the required driving position; the base description alone cannot establish the final height.
Are Sparco Sprint and Cobra Monaco Pro the same base pattern?
Their listed base patterns differ: Sprint 345 x 271 mm and Monaco Pro 292 x 330 mm, so check the actual seat and chosen mounting method.
Can any base-mounted recliner use the same fitting kit?
Compare both dimensions and the supplied rails: Sparco choices here use 345 x 271 mm, Auto Style BS5 uses 345 x 280 mm and OMP RTS is listed at 345 x 270 mm.
Which supports should I use with a Cobra Nogaro?
SUBFR31 is the Nogaro-specific support option; confirm the complete Cobra seat and vehicle-frame assembly.
Does the full bolt-in SW cage need welding?
The maker specifies weld-in foot plates and a cage that passes through the dashboard, so arrange the complete installation with the maker before ordering.
Can I fit this cage with a factory sliding sunroof?
The current shop description excludes factory-fitted sliding sunroofs; confirm the exact roof and body application with SW before ordering.
Does the MSUK description approve the cage for every event?
Confirm the exact cage specification, fitted installation and current championship rules with the maker; a material or tube-size compliance statement does not establish approval for every event.
Does a harness strap count decide its anchor points?
Follow the belt maker's installation instructions for the actual seat and vehicle, including attachment strength, routing and belt angles; three, four or six straps alone cannot establish a suitable installation.
More help
Send Garreth the Mk8’s build year, body and roof type, whether it is an ST, and the physical seating side. Include the exact seat model and whether you need one seat or a pair. Cameron can check the frame, supports, rails and restraint arrangement against those details.
Call 0115 647 8650 or use the contact link below with the specification.
