Ford Fiesta Mk5 bucket seat guide

2002 to 2008, including ST150

Seven fitting listings cover this Fiesta family, across OMP, Cobra, SW Motorsport and RECARO. Some are separate side selections, some are pair orders, and two RECARO listings use the same maker family. Garreth starts with the car’s build date and exact seat so those choices can be checked before you order.

This page covers the 2002 to 2008 Fiesta, including the ST150. Our guide title uses Mk5. Cobra and SW Motorsport use Mk6 for this generation, so keep the year and vehicle type with the enquiry. JD3 and JH1 appear in RECARO’s application table; the later JA8 Fiesta has different frame references.

Cameron checks the whole assembly from the vehicle base to the seat. A matching width alone leaves the front-to-back fixing pitch unanswered, and a runner may already be included with the seat or fitting kit. Choose the seat and its mounting route together.

Ford Fiesta Mk5 on track with a helmeted driver
Ford Fiesta ST150 Mk5 on track

Mounting

The lower frame connects the seat assembly to the car. A base-mounted seat then needs its underside fixing pattern matched to the upper parts. A side-mounted shell needs appropriate side supports and a compatible connection beneath them. Check the actual supplied parts before committing to either route.

Use the physical left or right side with each order. In a right-hand-drive Fiesta, the driver sits on the right and the passenger on the left. The shop’s parent reference can cover several selections, so record the chosen option as well as that reference.

OMP single frames, ST150 listing and pair order

The standard OMP single listing is HC845: HC845D is offered as RHD driver side and HC845S as RHD passenger side. HC845-X2 is the separate pair order. Confirm that the pair contains the correct frame for each position instead of ordering two of the same selected side.

The ST150 listing uses HC845D-ST150 and HC845S-ST150. These are separate shop selections within the HC845 family. Have the exact supplied application confirmed against your car before substituting between listings; the title or added ST150 suffix does not establish the physical differences between the parts.

Both single listings show 345 mm by 271 mm and 405 mm by 290 mm base patterns. The standard listing says fixing bolts are not supplied unless specified and that the original bolts may be unsuitable. Check the required hardware with the chosen frame and seat assembly, including any supports or runners above it.

Cobra frame and seat-specific assembly

Our Cobra ST150 listing has RHD driver, passenger and pair choices under SU-FO-ESMK5-ST150. Cobra’s application table identifies the 2002 to 2008 Mk6 BE256 Fiesta as SU-FOR-FIE-01L and SU-FOR-FIE-01R. Keep the actual maker code and physical side with the supplied kit; the shop’s LHD-labelled child reference is offered as the RHD passenger option.

Cobra’s reference sheet links that application to FRM-11. Its 405 mm assembly drawing shows Premium runners, a wide handle, a spacer bar and a seat-dependent belt bracket. The passenger arrangement reverses the spacer and belt-bracket positions shown for the UK driver side. Garreth would confirm this complete package before adding a separate runner kit.

The shop attribute gives 291 mm by 330 mm, while Cobra describes base-seat patterns of 292 mm or 405 mm across by 330 mm front to back. Check the exact seat and supplied configuration with Cameron, including any required Nogaro supports. The frame listing’s single pattern does not describe every Cobra seat arrangement. Cobra’s competition mounting guidance specifies side mounts without runners, so check that route separately from the reclining-seat assembly.

SW Motorsport lower base

The SW Motorsport Mk6 listing is the 2002 to 2008 base, including ST150 enquiries. Its current driver choice is SWS-Ford-Fiesta-Mk6-DR and the passenger choice is SWS-Ford-Fiesta-Mk6-PA. The description identifies supplied references SW-SM-0015 and SW-SM-0051 respectively. Match the selected side to the actual part before fitting.

Side supports or a slider assembly attach above the SW base. Those parts and the mounting hardware are separate from the base listing, with optional extras available. Match the 8 mm or 10 mm side-mount choice to the exact shell’s fixing requirements. The final seat height depends on all the parts above the floor.

The separate Zetec S Mk6 and ST150 SW listings repeat the same supplied references, SW-SM-0015 for the RHD driver and SW-SM-0051 for the RHD passenger. These are alternative order listings for the stated 2002 to 2008 base family. Confirm the exact car, seating side and selected upper mounting parts before ordering through either listing.

RECARO Fiesta-only listing

The Fiesta-only RECARO listing uses the compact parent reference 868616 and offers both RHD driver and passenger selections. RECARO’s table gives 86.86.16 on the left and 86.86.26 on the right for Fiesta JD3 and JH1 from May 2002. Confirm which full maker code is supplied for the selected side.

That listing describes integrated runners. Match the precise RECARO seat version to its application-table entry and required fitting parts before adding sliders or supports. A shared RECARO brand name does not establish that every base-mounted seat or competition shell works with this assembly.

RECARO Fiesta and Fusion listing

The combined Fiesta/Fusion listing offers 868626 as RHD driver side and 868616-sale as RHD passenger side. Those compact references correspond to the maker family’s right and left codes. It is an alternative listing to check for the required Fiesta position, with the exact seat and supplied package confirmed.

RECARO lists the European Fusion JU2 separately and requires spacer 373865 for that application. The shared frame family does not make the complete Fiesta and Fusion installations identical. A Fusion enquiry needs that separate application and its seat-specific requirements checked.

Separate Sparco runner option

Sparco 0049306 is a separate runner option for a compatible mounting assembly. Check both the seat-side and frame-side connections with the supplied parts. Where side supports are used, the specified runner arrangement goes beneath those supports as specified by the relevant fitting instructions.

Cobra Premium runner options

The Cobra Premium runner offers 291 mm and 405 mm handle-width choices. Check whether the selected Cobra fitting package already includes the required runners and handle. Adding another assembly can duplicate parts and alter the installed height.

Separate side supports

Sparco steel side supports are a separate catalogue option to assess with an appropriate shell. Other makers may require their own supports. Match the side-fixing centres and bolt sizes, then check the lower connection and the complete installation requirements.

Competition bucket seats

The OMP TRS-X is a fixed-back seat whose current listing includes base and side mounting, with a 345 mm by 271 mm base pattern. Keep it with the fixed shells when comparing seats. Its mounting choice still needs checking with the complete lower assembly.

The Champ-R, Mirco GT Velour, Mirco RS2 3D, Sparco Circuit QRT, Grid Q, Sabelt GT3 and Corbeau Sprint X are side-mounted candidates. The Auto Style BS6 is also a fixed shell, listed for Road and Track use. Check the approval label and exact version on the seat you order against your intended use.

The Sprint X listing gives FIA 8855-1999 as its approval. System 1 is part of the seat’s model description, so use the stated approval and actual label when choosing a seat. Garreth would compare the driver’s fit and available cabin space before choosing a shell size.

Measure shoulder clearance and the base position with the actual supports in the car, allowing for any helmet and cage you plan to use.

Reclining sport seats

The R100 and R333 both list a 345 mm by 271 mm base pattern. The Auto Style BS5 and Type JW list 345 mm by 280 mm, while the Type AK lists 405 mm by 280 mm. Those different front-to-back pitches need the correct intervening hardware. A shared width does not establish a complete connection to an OMP frame.

The Auto Style listings describe included sliders. Check their connections before buying another runner kit, and keep the seat model with the order so Cameron can assess the full mounting arrangement.

The Cobra Daytona adds a Cobra recliner to compare with the seats below. Confirm its actual fixing pattern against the seat-specific Cobra fitting package, given the shop and maker pattern differences described above. Backrest movement and adjustment need checking for clearance through the range you will use.

Tell Garreth if rear access is part of the brief so the chosen seat mechanism and installed position can be assessed together.

Roll cages

Custom Cages FF/03B is the bolt-in CDS listing for the Fiesta Mk5/Mk6 and ST150 family. The maker identifies the design as FIA certificated. Confirm the exact vehicle body, supplied design and certification requirements with the cage order.

FF/05T is the separate International Multipoint T45 listing. Its current shop specification is weld-in, with profiled tubes and footplates described in the kit. Plan that installation with the seat position and required access, then confirm the application and documentation for your build.

Harnesses

The harness choices below include TRS Clubman and Magnum, Takata Drift II and Drift III, and Schroth Profi 3×2. Choose the exact belt after the seat position is established, using its instructions to check the routing and anchorage layout.

Strap count does not establish suitable attachment locations. A three-point harness also needs its anchors and geometry checked. For four- or six-point arrangements, assess the required shoulder and lower attachment points with the actual seat and car. A cage being present does not establish that a particular tube is a suitable belt attachment.

Cameron checks the belt’s requirements with the chosen seat and any cage or harness bar. Keep the exact belt model with the fitting enquiry.

What fits

Compare both fixing dimensions and the supplied parts. The exact seat, selected side and vehicle application need checking as one assembly.

Route or seatSide or fixingPattern or contentsCheck before ordering
OMP HC845 / ST150 / X2Single side or pair listing345 x271 /405 x290 mm shop base patternsCheck exact supplied application, seat interface and hardware
Cobra Fiesta BE256SU-FOR-FIE-01L /01RMaker FRM-11, seat-specific runner assemblyShop291 x330 differs from maker292/405 x330 patterns; confirm seat configuration
SW Motorsport Mk6 baseDriver DR /passenger PA selectionsSupports, sliders and hardware separateExact shell bolt size and upper connections
RECARO Fiesta /Fiesta-Fusion86.86.16 left /86.86.26 rightExact seat version and supplied assemblyFusion JU2 separately requires373865 spacer
OMP TRS-X fixed shellBase or side mounting listed345 x271 mm base patternKeep fixed-shell classification; assess complete lower assembly
Other fixed shells in this guideSide supports requiredExact shell width and fixing pointsChamp-R, Mirco GT/RS2, Circuit QRT, Grid Q, Sabelt GT3, Sprint X and BS6
Sparco R100 /R333 reclinersBase mount345 x271 mmCheck runners, backrest travel and cabin clearance
Auto Style BS5 /JW reclinersBase mount, included sliders described345 x280 mm280 mm pitch differs from Sparco271 mm
Auto Style AK reclinerBase mount, included sliders described405 x280 mmCheck both dimensions; OMP wider pattern is405 x290 mm
Cobra Daytona reclinerCobra seat-specific configurationVerify actual seat and maker fitting packageShop/maker pattern difference needs confirming

Common questions

This page covers the 2002 to 2008 Fiesta, including ST150. Our title uses Mk5, while Cobra and SW Motorsport call this generation Mk6. Confirm the year and vehicle type with the selected kit.

Confirm the vehicle type and build date because 2008 is a changeover year. RECARO lists JD3/JH1 against 86.86.16/26 and the later JA8 against another frame family. Do not choose on registration year alone.

They are separate shop selections within the HC845 family. Confirm the actual supplied application before substituting between them. A shared stem or added ST150 suffix does not establish the physical differences between the parts.

HC845-X2 is the separate pair listing. The HC845 and HC845-ST150 single listings each have driver and passenger choices. Confirm the supplied frame for each required position.

The standard listing says bolts are not supplied unless specified and that original equipment bolts may be unsuitable. Check the hardware requirements for the selected frame and all intervening mounting parts.

Cobra lists the 2002 to 2008 BE256 Fiesta under SU-FOR-FIE-01L and SU-FOR-FIE-01R. Its reference sheet links these to FRM-11. Confirm that the supplied kit matches the physical side and exact seat.

The shop listing describes a runner in the package, and Cobra's FRM-11 drawing shows Premium runners and a handle. Confirm the seat-specific package before adding another set.

It is the lower vehicle base. Side supports, sliders and mounting hardware are separate choices. Check each upper connection and bolt size with the actual shell.

The installed position depends on the seat, supports and any runners above the base. Check the complete assembly in the car before relying on a height change.

It is physical right, matching the RHD driver position. The corresponding left-hand maker code is 86.86.16. Confirm the full code on the supplied frame and the selected shop option.

One is labelled for Fiesta and one for Fiesta/Fusion. Both need checking against the required Fiesta side and exact RECARO seat version. The parent reference alone does not describe the full supplied assembly.

RECARO lists Fusion JU2 separately and requires spacer 373865 for that application. Confirm the complete Fusion assembly and seat-specific requirements separately from the Fiesta.

Its current listing includes base and side mounting and gives a 345 mm by 271 mm base pattern. It remains a fixed-back seat. Confirm the chosen mounting route with the lower frame and required hardware.

The Sparco R100/R333 list 345 mm by 271 mm, the Auto Style BS5/JW list 345 mm by 280 mm, and the AK lists 405 mm by 280 mm. Check both dimensions and the supplied sliders before choosing the fitting assembly.

Use the seat's stated approval and actual label. The Sprint X System 1 listing gives FIA 8855-1999. The System 1 model wording does not replace that approval reference.

FF/03B is the bolt-in CDS listing. FF/05T is the separate T45 multipoint listing with a weld-in specification. Confirm the supplied design and application before planning the installation.

That needs checking against the exact belt's instructions and the actual anchorage layout. Set the seat position first. Neither strap count nor the presence of a cage confirms suitable attachment geometry.

Send the build date and vehicle type, steering side, seat model and selected frame option. Include any runner or support references already fitted to the car. That lets Garreth and Cameron assess the complete order.

More help

Send Garreth the Fiesta’s build date, vehicle type and steering side, plus the exact seat model. Include the selected frame option and any runners you already have so Cameron can check the parts together. Photographs of the existing hardware help identify what is already in the car.

For help with your Fiesta or ST150 seat and fitting kit, call 0115 647 8650.
