Honda CR-Z bucket seat guide

2010 to 2016

It is a hybrid, so read this first. The CR-Z carries high-voltage cabling and a battery pack, plus the usual low-voltage wiring under the seats. If you are not entirely certain what runs where, have the work done by someone who is. This is not a car to unbolt and work out afterwards.

The CR-Z is Honda’s attempt at a sporting hybrid: a two-seat coupe with a manual gearbox, which nobody else has tried before or since. It is light, it is not fast, and it has a small and committed following precisely because of that. People fit shells to them for weight and for support in club events, where being light matters more than being powerful.

Because the car is light, a heavy steel-framed shell gives back a real slice of the advantage, so it is worth asking about the lighter GRP options. The cabin is also tighter than it looks; tell us your height and build and we will check what actually fits.

Honda CRZ on track with a helmeted driver
Honda CR-Z on track

Mounting

High-voltage hybrid system: know what you are doingThe CR-Z carries high-voltage cabling and a battery pack alongside the usual low-voltage wiring under the seats. If you are not entirely certain what runs where, have the work done by someone who is. This is not a car to unbolt and work out afterwards.

For the M2 route, specify the physical seating side and the exact bucket seat. M2 identifies M2-2H017-0000 for the left side and M2-2H017-0010 for the right, with 290mm seat-hole centres. Its rail description is for bucket seats and excludes original and reclining seats. Confirm the selected assembly and supplied upper brackets with the complete shell reference.

The single M2 listing and the pair option below need their supplied parts checked before ordering. For a pair, ask us to confirm both physical side references and the components for each seat.

The Planted bracket is a separate fitting route. Match the selected vehicle bracket to the seat connection and any runner kit as one assembly. Side mounts and sliders shown here each need that interface check.

Tell Cameron which parts are already in the car so we can check the proposed complete assembly.

Competition bucket seats

The Endurance Motorsport Club Sport at £209.79 and Circuit at £296.10 are accessible non-FIA options. Most of the remaining seats carry FIA 8855-1999 approval. The Cobra Suzuka T Pro-Fit at £561 is a premium option. The Cobra Monaco Pro at £235 is the accessible steel-shelled alternative.

Because this car is light, the fibreglass options are worth prioritising: the OMP Champ-R at £318, OMP ARS-R at £428 and Mirco RS2 3D at £354.50. The Sparco Rev QRT at £345 and Evo QRT at £475 sit at the upper end. The Auto Style Type RR at £254.60 rounds out the accessible options.

💬
Competition seats for the CR-ZWhich bucket seat for a Honda CR-Z

On a car this light, the OMP Champ-R at £318 is a lighter FIA-rated fibreglass option worth the extra over a heavier steel shell. The Cobra Monaco Pro at £235 is the accessible steel-shelled alternative if the car sees contact. For a CR-Z built properly for club events, the Sparco Evo QRT at £475 gives strong support through fast corners. Talk to us with the seat dimensions and confirm the fitting frame before ordering.

Reclining sport seats

For a reclining seat, start with its base mounting pattern and the appropriate CR-Z floor bracket. M2 excludes reclining seats from the bucket-seat rails listed above. Send Cameron the exact seat reference and proposed runner kit so the lower vehicle connection can be checked.

The reclining models shown below are options to enquire about. Check the full assembly and its movement in the actual cabin before choosing the seat. Include the backrest adjustment and the space needed to reach its controls.

💬
Reclining seats for the CR-ZWhich recliner for a Honda CR-Z

The Sparco R100 Vinyl at £235 is a sensible road-car starting point, a real step up from the factory seat. The Sparco R333 at £374.56 is worth the jump if the car sees regular club events. For a full interior rebuild, the Sparco SPR at £1549.12 is the seat in this guide built to that standard.

Harnesses

Harnesses need a roll cage or harness barA 4-point, 5-point or 6-point harness with separate shoulder straps needs proper attachment points above and behind the seat. Fit a roll cage or a properly engineered harness bar before using anything above a 3-point belt. No roll cage confirmed for this car currently exists in the catalogue; contact us if you need one.

The TRS Clubman 3-point bolt-in at £80 and 4-point clip-in at £100 both use the standard seat belt anchor points and do not need a cage. For 4-point competition use, the TRS Magnum 4-point FIA at £205 and the Takata Drift II at £229 are the step up.

For 6-point harnesses, proper anchor points are needed first. The TRS Magnum 6-point Superlite FIA at £245, the Takata Drift III at £270, and the Schroth Profi 3×2 at £370 are all suitable once those points exist.

What fits

Mounting route and approval for every seat in this guide.

SeatMountingApprovalNotes
Competition bucket seats
Endurance Motorsport Club SportSide mountRoad and TrackNon-FIA.
Endurance Motorsport CircuitSide mountRoad and TrackNon-FIA.
Auto Style Type RRSide mountRoad and TrackNon-FIA.
Cobra Suzuka T Pro-Fit FIASide mountFIA 8855-1999Premium build.
Cobra Monaco Pro FIABase mount and side mountFIA 8855-1999Steel shell. Dual mount.
OMP Champ-R FIASide mountFIA 8855-1999HANS compatible.
OMP ARS-R FIASide mountFIA 8855-1999Broadest fit band.
Mirco RS2 3D FIASide mountFIA 8855-1999Fibreglass shell.
Sparco Rev QRT FIASide mountFIA 8855-1999
Sparco Evo QRT FIABase mount and side mountFIA 8855-1999Dual mount.
Reclining sport seats
Auto Style Type BS5Base mountRoad and Track
Auto Style Type JWBase mountRoad and Track
Auto Style Type AKBase mountRoad and Track
Sparco R100 VinylBase mountRoad and Track
Sparco R333Base mountRoad and Track
Cobra Misano AnniversaryBase mountRoad and TrackPremium reclining seat.
Corbeau Sportline RRS Leather EliteBase mountRoad and Track
Sparco SPRBase mountRoad and TrackPremium reclining seat.

Common questions

The CR-Z carries high-voltage cabling and a battery pack alongside the usual low-voltage wiring under the seats. Have the work done by someone who knows exactly what runs where. This is not a car to unbolt and work out afterwards.

The car is light to begin with, so a heavy steel-shelled seat gives back a real slice of that advantage. If the build is about club event performance, the lighter GRP options are worth prioritising.

Yes, tighter than it looks. Tell us your height and build before ordering a shell, and we will check what actually fits.

Not currently, as far as we have found in the catalogue. Contact us if you need one and we will point you toward a bespoke solution.

No. A 6-point harness needs anchor points above and behind the seat for the shoulder straps. Fit a roll cage or a properly engineered harness bar first. A 3-point bolt-in harness uses the standard seat belt anchor points and does not need a cage.

M2 describes this CR-Z rail family for bucket seats and excludes original and reclining seats. A recliner needs its own confirmed seat, runner and vehicle bracket combination. Send us the complete seat reference before choosing the fitting route.

More help

Given the high-voltage system, talk to us before starting the job, and tell us your height and build so we can check what actually fits in a cabin this tight. Cameron works through the seat, frame and car combination together.
