Top 5 reclining seat choices for your Mazda MX-5 Mk1 and Mk2, including our fitting guide

The MX-5 is a car that rewards feel more than outright power, and the factory seats reflect that: comfortable enough for a long run but without the lateral support to match how the chassis handles a fast corner. That is the conversation we have most often with MX-5 owners in the showroom. The second one is with taller drivers who find the standard seat puts them too high once a rollbar or half cage is in.

This guide covers the five reclining seats we recommend for the Mk1 NA (1989 to 1997) and Mk2 NB (1998 to 2005), and there are two ways of mounting them. Four of the five go on the Cobra H-frame adaptor bars (14306), which bolt onto the top of the car’s existing H-shaped floor frame instead of replacing it, so the factory forward and back adjustment carries over and there is no runner kit to buy. The fifth, the Auto Style BS5, is drilled to a different pattern and goes in on a Planted bracket instead. Both routes are covered below.

  • Main route: Cobra H-frame adaptor bars, £52.80 inc VAT a set, one set per seat
  • The adaptors sit on top of the existing H-shaped floor frame and preserve factory seat sliding
  • Four of the five seats use the 291mm x 330mm Cobra bolt pattern; the Corbeau PSR is drilled for that and the Sparco pattern
  • The Auto Style BS5 is 345mm x 280mm, so it takes the Planted bracket route instead, Mk1 NA only
  • The original H-frame must be in sound condition before fitting; inspect it before ordering
White Mazda MX-5 Mk1 NA with a helmeted driver cornering on a wet British circuit
The Mazda MX-5 Mk1 NA. The Cobra H-frame adaptor bars are the route most owners take, because they keep the car’s own sliding frame.

The H-frame adaptor route

Most cars in this programme need a replacement subframe that bolts to the floor in place of the factory seat rails. The MX-5 works differently. The Mk1 and Mk2 both use an H-shaped sliding frame that runs between the seat and the floor, and the Cobra adaptor bars (14306) bolt to the top of that existing frame rather than removing it. The H-frame continues to do the sliding, so the factory seat adjustment carries over to the new seat. That is a genuine practical benefit on a car people drive every day: you keep the position range you are used to, and there are no additional runners to source and fit.

291

Cobra H-frame adaptor bars

Part 14306, £52.80 inc VAT a set, one set per seat. Bolts to the car’s existing H-shaped sliding frame and takes any seat with the 291mm x 330mm Cobra pattern. The Corbeau PSR fits too, because Corbeau drill it for both the Cobra and Sparco patterns. Mk1 and Mk2.

SB

Planted SB101 bracket

£224.95 inc VAT a side. Replaces the mounting instead of adapting it, and the seat’s own sliders bolt to the bracket. Pre-slotted for most makers’ sliders with spare material to drill a less common pattern. This is the route for the Auto Style BS5. Mk1 NA only.

Check the H-frame before orderingThe adaptor bars bolt to the original frame and rely on it for rigidity. If the H-frame is bent, corroded or missing, the adaptors will not sit flat and the seat will not be secure. Inspect it before you order. If there is any doubt, get in touch and we can advise before you buy.

The bolt pattern that matters

Every seat here bolts down through a base mount pattern, and the pattern is what decides which route you are on. Cobra recliners use 291mm x 330mm, which is what the H-frame adaptor bars are drilled for, and the Daytona, Le Mans, Heritage and Misano all share it. The Corbeau PSR is drilled for both that and the 345mm Sparco pattern, which is why it fits the bars as well. The Auto Style BS5 is the odd one out at 345mm x 280mm. That is the Auto Style house pattern, not something odd about this one seat, but it does not line up with the Cobra bars, so the BS5 goes in on a Planted bracket instead. A standard Sparco recliner has the same problem and there is no route for one on this car at the moment.

SeatBolt patternCobra H-frame adaptorsPlanted SB101
Corbeau PSRBothFitsNot needed
Cobra Daytona291 x 330FitsNot needed
Cobra Le Mans / Heritage291 x 330FitsNot needed
Cobra Misano Anniversary291 x 330FitsNot needed
Auto Style Type BS5345 x 280Does not fitMk1 NA, drilled to suit
Two routes, and a lot of others we have not listed hereThe adaptor bars and the Planted bracket are the two routes that matter for reclining seats. They are not everything we stock for an MX-5: there are PCI sub frames and adjustable mounts, Cybul and Endurance side mounts, Jass adapter rails and BRIDE rails as well, but those are aimed at side mount bucket seats, not recliners. If you have a seat in mind that is not in this guide, ring us with the bolt pattern before you buy anything and we will tell you whether there is a route for it.

Corbeau PSR: the confirmed non-Cobra fit

The Corbeau PSR is the one recliner outside the Cobra family that we can confirm fits the MX-5 H-frame adaptor bars. Corbeau drill the PSR for both the 291mm Cobra pattern and the 345mm Sparco pattern, which is how it works here. We verified the installation on a Mk1 NA and wrote up the full process, so there is already a Corbeau PSR MX-5 fitting guide on the site covering exactly this combination. If the PSR is the seat you want, read that alongside this guide.

It comes as a pair, both seats in one order at £558 inc VAT. Individual seats are available at £279 each if only one side needs replacing, though most customers do both sides when the conversion is right.

  • Pair £558.00 inc VAT; £279.00 each individually
  • Drilled for both 291mm Cobra and 345mm Sparco patterns
  • Confirmed fit on Mazda MX-5 Mk1 NA with H-frame adaptor bars
  • Harness slots, listed 4 point compatible
  • Full fitting guide at sportseats4u.co.uk for this exact combination

Cobra Daytona: the support pick

The Daytona is the seat Cameron puts most MX-5 customers in when they want proper lateral support for track work. The bolsters at the shoulders and thighs are deeper than anything else in this guide, so your body stays put through the quick stuff and your arms do the steering. It is also where the Cobra Signature range starts: you can have the Daytona in any trim combination, from plain black cloth through to two-tone leather with contrast stitching, and there is a heating and lumbar option if the car covers winter miles. The Tartan Edition is the ready-to-order version for anyone who wants the distinctive look without speccing it from scratch.

  • £599.00 inc VAT, built to order in your trim choice
  • Tartan Edition £899.00 inc VAT as a ready-configured option
  • 32 to 38 inch waist, all heights; 13.5kg; 865mm tall and 580mm wide
  • Cobra Signature trim options; optional heating and lumbar
  • 291mm x 330mm pattern, fits the Cobra H-frame adaptor bars

Cobra Le Mans and Le Mans Heritage: the retro build pick

This is the seat for the MX-5 that is being built to look like something, not to lap something. An NA is a 1989 car drawn from 1960s roadsters, and the quickest way to spoil that is to drop a pair of modern competition shells into it. Cobra put it well themselves: timeless lines with a retro twist, and it suits a custom or retro interior in a way a competition shell cannot. If you want the seats to look as though they came with the car instead of looking like an upgrade, this is the shape to start from.

The reason it works is the backrest. The Le Mans has an orthopaedic style back that supports the length of your spine instead of gripping your ribs, so the bolstering stays shallow and the seat keeps a low, wide, period profile. That is also why it is the one to have if the car does proper mileage. It is the heaviest seat Cobra make at 13.4kg, which is the price of a steel reclining chassis, and on a 950kg car that is worth knowing before you order two.

For a period interior, take the Heritage. The difference is not trim colour, it is fluted centre panels and no logos anywhere on the seat. Fluting is a period detail and the absence of branding is what stops a modern seat announcing itself in a classic cabin, which is exactly the problem on a retro MX-5. Cobra will trim it with basketweave or corduroy centres if you want to go further back again. Same shell, same mechanism, same dimensions as the standard Le Mans, £649 inc VAT against £619. Both are hand trimmed in the UK, so you give us the colours at checkout and we confirm the design before the seat is built.

  • Le Mans £619.00 inc VAT; Le Mans Heritage £649.00 inc VAT
  • Heritage difference: fluted centre panels and no logos anywhere on the seat
  • 820mm tall, 540mm wide, 620mm deep on a 540mm base; 13.4kg
  • Orthopaedic style backrest, shallower bolstering than the Daytona
  • Road and Track approved, not FIA homologated, so road and show use
  • 291mm x 330mm pattern, fits the Cobra H-frame adaptor bars

Auto Style Type BS5: the compact one, on a different bracket

The BS5 is the seat to look at when the budget matters and the cabin is the problem. It is a reclining seat with a fibreglass reinforced backrest on a steel frame, so the back panel stays put under cornering load in a way a plain steel recliner does not, and it sits on the narrower 345mm base that Auto Style use across most of their range, not the 405mm base of their bigger seats. At £354 inc VAT a seat, or £696 for the pair, it is less than half the price of anything else on this page and the sliders come in the box.

Two things to be straight about. Auto Style size it for drivers under 6ft, and that is the only physical limit on it, because the waist range covers everybody. And it is 16.3kg, which is the heaviest reclining seat in their 345mm range and heavier than any Cobra here. On a car whose whole character is its lack of weight, two of them is not a small decision.

The fitting is the part that needs saying properly. The BS5 is drilled 345mm x 280mm, so it will not bolt to the Cobra H-frame adaptor bars, whatever else you read. The route is a Planted SB101 bracket, which replaces the mounting instead of adapting it and takes the seat’s own sliders on top. Planted pre-slot that bracket for sliders from most of the major makers and leave spare material to drill a less common pattern, and Auto Style are not on their list, so plan on drilling it to suit. The SB101 is also NA chassis only, 1989 to 1997, so this is a Mk1 answer and not a Mk2 one. If that is your car and you want a supportive recliner without spending Cobra money, ring us and we will talk it through before you order either part.

  • £354.00 inc VAT a seat; £696.00 inc VAT the pair
  • Fibreglass reinforced backrest on a steel frame; sliders included
  • Drivers under 6ft only; all waist sizes; 16.3kg
  • Road and Track approval, 4 point harness compatible, no head support
  • 345mm x 280mm pattern, so it does NOT fit the Cobra adaptor bars
  • Goes in on a Planted SB101, Mk1 NA only, slider holes drilled to suit

Cobra Misano Anniversary: the premium pick

The Misano Anniversary is the best reclining seat Cobra make, and the one we point at MX-5 owners who want the seat to feel as though the car was built around it. The bolsters are deep, the cushioning is where the money went, and despite being the most substantial seat in this guide it is also the lightest at 11.5kg. It comes through the same Cobra Signature trim system as the Daytona, so the colour, material, stitching and options are yours to configure. At £1649 inc VAT it is at the top of the list. In the showroom, nobody who has sat in one has walked out asking for the cheaper seat instead.

  • £1649.00 inc VAT
  • 32 to 38 inch waist, all heights; 11.5kg; 885mm tall and 590mm wide
  • Cobra Signature trim: fabric, vinyl or leather in any colour combination
  • Optional heating and lumbar support
  • 291mm x 330mm pattern, fits the Cobra H-frame adaptor bars

Getting it bolted down

For the four Cobra pattern seats, the Cobra H-frame adaptor bars (14306) come as a set of two bars per seat. They bolt to the top of the car’s existing H-shaped floor frame and the seat bolts onto the bars. The H-frame does the sliding, so the factory adjustment carries over and there are no runners to buy. For the BS5 it is the other way round: the Planted SB101 replaces the mounting, and the seat’s own sliders bolt to the bracket.

Your seatWhat to orderAdditional parts
Corbeau PSRCobra H-frame adaptor bars (14306), one set per seatNone. The H-frame does the sliding.
Cobra Daytona, Le Mans, Le Mans Heritage, Misano AnniversaryCobra H-frame adaptor bars (14306), one set per seatNone. The H-frame does the sliding.
Auto Style Type BS5Planted SB101 bracket, one per side. Mk1 NA only.None to buy. The seat’s own sliders are included, and the bracket will need drilling to match them.

Before fitting: confirm the H-frame is clean and undamaged. Torque the adaptor bar bolts to the frame, then torque the seat bolts to the adaptors. Check seat belt buckle clearance with the seat in the furthest forward position before driving, because a sport seat often relocates the buckle relative to where the standard seat left it.

The Cobra seats in this guide are listed individually; fitting both sides of the car means two orders. The Corbeau PSR is the exception and comes as a named pair, both seats in one order at £558 inc VAT.

The five compared

SeatBolt patternWaistDriver heightWeightPrice inc VAT
Auto Style Type BS5345 x 280All sizesUnder 6ft16.3kg£354, £696 a pair
Corbeau PSRBoth32 to 38inAll heightsNot published£558 a pair
Cobra Daytona291 x 33032 to 38inAll heights13.5kgFrom £599
Cobra Le Mans291 x 33032 to 38inAll heights13.4kgFrom £619
Cobra Misano Anniversary291 x 33032 to 38inAll heights11.5kgFrom £1649

Prices include VAT and were correct on 19 September 2026. Where a figure says not published, the manufacturer does not provide it and we will not guess it. The BS5 is the only seat here with a driver height limit, and the only one that does not go on the Cobra adaptor bars. If you are on a boundary for any of them, contact us with your measurements before ordering.

Common questions

Do the Cobra adaptor bars work on both Mk1 NA and Mk2 NB?

Yes. The Cobra H-frame adaptor bars (14306) are listed for the Mazda MX-5 H Frame, which covers both the Mk1 NA (1989 to 1997) and Mk2 NB (1998 to 2005). Both generations use the H-shaped floor frame. If your car has had floor work or the H-frame has been removed, check before ordering.

Why does the Auto Style BS5 need a different bracket?

Because of the bolt pattern. The Cobra adaptor bars are drilled 291mm x 330mm and the BS5 is 345mm x 280mm, which is the pattern Auto Style use across most of their range. The two do not line up, so the BS5 goes in on a Planted SB101 bracket instead, with the seat’s own sliders bolted to it. Planted leave spare material on the bracket for drilling a less common slider pattern, which is what this is. The SB101 is for the NA chassis only, so the BS5 is a Mk1 answer.

Do I need sliding runners as well as the adaptor bars?

No. The adaptor bars bolt onto the existing H-frame, and the H-frame itself provides the sliding movement. The factory forward and back adjustment carries over to the new seat. You do not need a separate runner kit on that route. The BS5 is different again: it comes with its own sliders in the box, and those bolt to the Planted bracket.

Can I fit a Sparco seat on the Cobra adaptor bars?

No. Cobra adaptor bars accept the 291mm x 330mm Cobra bolt pattern. Sparco recliners use 345mm x 271mm, so a standard Sparco seat will not bolt to these bars. The Corbeau PSR is the only non-Cobra seat that fits them, because Corbeau drill it for both patterns. If you have a seat in mind that is not in this guide, contact us with its bolt pattern before you buy and we will check it.

Is the Cobra route really the only way to mount a seat in an MX-5?

No, and we should be clear about that. It is the route that suits reclining seats, because it keeps the car’s own sliding frame and costs very little. We also stock Planted brackets, PCI sub frames, adjustable mounts and one piece mounts, Cybul and Endurance side mounts, Jass adapter rails and BRIDE rails for these cars. Most of those are aimed at side mount bucket seats, not recliners, which is why they are not the answer on this page.

What condition does the H-frame need to be in?

The adaptor bars bolt to the top of the existing H-frame and rely on it for the seat’s rigidity and for the sliding function. If the H-frame is bent, corroded or damaged, the adaptors will not sit flat and the seat will not be secure. Inspect the H-frame before you order. If there is any doubt, contact us and we can advise.

Will these seats take a harness?

Every seat in this guide is listed by the manufacturer as 4 point harness compatible, with belt slots in the backrest. Fitting a harness on a road car brings additional requirements: a harness-compatible seat, the correct eyebolts or harness bar, and proper lap belt anchorage. If you are planning harnesses, mention it when you order and we will make sure the whole setup works together before anything goes in the car.

What I would actually buy

The Corbeau PSR is the seat to start with if you want the decision already made. There is a full fitting guide for this exact combination on an MX-5 already on the site, the pair price covers both sides of the car in one order, and you know before you buy that it works. That is worth something on a conversion where the frame route is the unusual one.

For a single seat on the Cobra route, the Daytona, because the bolsters are deeper than anything else at that price and the Signature range means you can have it in whatever trim suits the car. If the MX-5 is a retro build and not a track car, take the Le Mans, and take the Heritage version if the interior is period: fluted panels, no logos, and a shape that looks like it belongs in an NA. And the Misano Anniversary is the best seat in this guide. There is not a more honest way to put it.

The Auto Style BS5 is the one to ask us about before you order off the page. It is a lot of seat for £354 and the pair costs less than one Le Mans, but it only suits a Mk1, it wants a Planted bracket drilled to match its sliders, and it is the heaviest seat here. If that is your car and your budget, it is a good answer. If any of those three things is wrong, it is the wrong seat and we will say so.

Cameron works out which of these suits a specific car and driver, one conversation at a time. If you are between two seats or not sure which way to go on this car, call 0115 647 8650 and we will talk it through before you spend anything.
