Hyundai i30 N bucket seat guide
PD generation, 2017 onwards
This guide covers the Hyundai i30 N. Match the exact body, build and steering side to the selected vehicle fittings. The SW Motorsport base linked here is listed for right-hand-drive cars.
A competition shell and a reclining seat each need a complete connection to the car. Include the exact seat, runner or fixed connection, supports where required and the selected vehicle base in the check. Tell us which parts you intend to retain.
- The subframe and both roll cages in this guide are built for the i30 N specifically, not the standard i30. Confirm your car is an N before ordering vehicle-specific kit
- The linked SW Motorsport base is listed for the right-hand-drive i30 N; check the supplied physical side and complete mounting package.
- For a reclining seat, check the runner fixings and the vehicle floor connection together. A supplied runner alone does not confirm that lower assembly.
- Two dedicated i30 N half cages available, from JP Cages and SW Motorsports
- Harnesses above 3-point need a roll cage or a properly engineered harness bar
Mounting
The SW Motorsport listing names base SW-SM-0134 and offers RHD driver or passenger options. The base fixes to the vehicle mounting points. Side supports, sliders and fitting bolts are listed separately.
A supplied runner does not establish the connection to the i30 N floor. Match its lower fixings to a confirmed vehicle-specific base or complete fitting kit. Check the seat-to-runner and lower vehicle interfaces before ordering.
-
From £134.89 Incl. VATFrom £112.41 Excl. VATPayPal CreditSelect options This product has multiple variants. The options may be chosen on the product page
Competition bucket seats
The OMP TRS-E Velour at £199.50 and Cobra Monaco Pro at £235 are the accessible FIA-rated starting points. The Mirco RTS-2 Velour at £349 and RS2 3D Fibreglass at £354.50 sit a step up.
The OMP Champ-R at £318 is a lighter fibreglass option. The Sparco Evo L QRT at £510 and the OMP RT Carbon/Fibreglass at £589.97 are the premium options for an i30 N being built properly for competition.
-
From £244.40 Incl. VATFrom £203.67 Excl. VATPayPal CreditSelect options This product has multiple variants. The options may be chosen on the product page
-
From £418.80 Incl. VATFrom £349.00 Excl. VATPayPal Credit250+ coloursKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
-
From £425.40 Incl. VATFrom £354.50 Excl. VATPayPal Credit250+ coloursKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
-
From £282.00 Incl. VATFrom £235.00 Excl. VATPayPal CreditKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
-
From £712.96 Incl. VATFrom £594.13 Excl. VATPayPal CreditKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
💬
Competition seats for the i30 NWhich bucket seat for a Hyundai i30 N
For a track day car, the OMP TRS-E Velour at £199.50 is the practical FIA-rated starting point on the subframe above. If the car sees contact, the Cobra Monaco Pro at £235 trades some weight for a steel shell. For an i30 N built properly for circuit work, the OMP RT Carbon/Fibreglass at £589.97 gives the strongest support through fast corners. Confirm side mount or dual mount fixing before ordering.
Reclining sport seats
For a reclining seat, send us the exact seat reference and runner kit before choosing the lower fittings. We need to check how the runner joins the proposed vehicle base. Include the adjustment you want and any parts already fitted to the car.
The Corbeau pairs shown here also need quantities checked for each seat position. Check what comes with the seats and which lower components are separate. Keep the retained buckle connection with that parts list.
-
From £282.00 Incl. VATFrom £235.00 Excl. VATPayPal CreditSelect options This product has multiple variants. The options may be chosen on the product page
-
From £461.00 Incl. VATFrom £384.17 Excl. VATPayPal CreditKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
-
From £282.00 Incl. VATFrom £235.00 Excl. VATPayPal CreditKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
💬
Reclining seats for the i30 NWhich reclining seat for a Hyundai i30 N
The Sparco R100 at £235 is the sensible starting point, comfortable for road use with enough side support for a spirited drive. For a pair fitted together, the Corbeau PSR at £465 gives a genuine step up in bolster support without going to a fixed-back shell. All of these keep more factory comfort than a competition bucket, and none of them need the i30 N-specific subframe.
Roll cages
Two dedicated i30 N half cages: the JP Hyundai I30N Half Cage at £461, and the SW Motorsports Bolt In Half Roll Cage at £480.83. The JP Cages DIY Half Cage Kit at £295.62 is the budget option for a fitter comfortable doing the work themselves.
-
From £577.00 Incl. VATFrom £480.83 Excl. VATPayPal CreditMade to orderKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
-
From £553.20 Incl. VATFrom £461.00 Excl. VATPayPal CreditMade to orderKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
-
From £354.74 Incl. VATFrom £295.62 Excl. VATPayPal CreditMade to orderKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
Harnesses
Harnesses need a roll cage or harness barA 4-point, 5-point or 6-point harness with separate shoulder straps needs proper attachment points above and behind the seat. Fit a roll cage or a properly engineered harness bar before using anything above a 3-point belt.
The TRS Clubman 3-point bolt-in at £80 and 4-point clip-in at £100 both use the standard seat belt anchor points and do not need a cage. For 4-point competition use, the TRS Magnum 4-point FIA at £205 and the Takata Drift II at £229 are the step up.
For 6-point harnesses, the cage goes in first. The TRS Magnum 6-point Superlite FIA at £245, the Takata Drift III at £270, and the Schroth Profi 3×2 at £370.01 all suit a caged i30 N going to competition or serious track days.
-
From £96.00 Incl. VATFrom £80.00 Excl. VATPayPal CreditAmazing valueSelect options This product has multiple variants. The options may be chosen on the product page
-
From £120.00 Incl. VATFrom £100.00 Excl. VATPayPal CreditAmazing valueSelect options This product has multiple variants. The options may be chosen on the product page
-
From £246.00 Incl. VATFrom £205.00 Excl. VATPayPal CreditAmazing valueSelect options This product has multiple variants. The options may be chosen on the product page
-
From £274.80 Incl. VATFrom £229.00 Excl. VATPayPal CreditSelect options This product has multiple variants. The options may be chosen on the product page
-
From £294.00 Incl. VATFrom £245.00 Excl. VATPayPal CreditAmazing valueSelect options This product has multiple variants. The options may be chosen on the product page
-
From £324.00 Incl. VATFrom £270.00 Excl. VATPayPal CreditKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
-
From £444.01 Incl. VATFrom £370.01 Excl. VATPayPal CreditKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
What fits
Approval for every seat in this guide.
| Seat | Mounting | Approval | Notes |
|---|---|---|---|
| OMP TRS-E Velour FIA | Subframe, base mount and side mount | FIA 8855-1999 | Dual mount. |
| Cobra Monaco Pro FIA | Subframe, base mount and side mount | FIA 8855-1999 | Steel shell. Dual mount. |
| Mirco RTS-2 Velour FIA | Subframe, side mount | FIA 8855-1999 | |
| Mirco RS2 3D Fibreglass FIA | Subframe, side mount | FIA 8855-1999 | |
| OMP Champ-R FIA | Subframe, side mount | FIA 8855-1999 | HANS compatible. |
| Sparco Evo L QRT FIA | Subframe, side mount | FIA 8855-1999 | |
| OMP RT Carbon/Fibreglass FIA | Subframe, side mount | FIA 8855-1999 | |
| Sparco R100 Reclining | Confirm base, runner and seat interfaces | Road use | Vinyl option available. |
| Corbeau reclining pairs | Confirm base, runner and seat interfaces | Road use | Sold as a pair. |
Common questions
Does this guide cover the standard i30, not just the N?
No. We do not stock a subframe or roll cage for the standard i30, only the N. Every vehicle-specific part in this guide is built for the N hot hatch.
Do I need the subframe for a reclining sport seat?
A reclining seat needs a confirmed connection to the vehicle. Runners supplied with a seat do not by themselves confirm that lower interface. Check the exact seat, runner and vehicle-specific base or complete fitting kit as one assembly.
Which side does the subframe come in?
RHD driver side or RHD passenger side. Confirm which you need when ordering.
Can I run a 6-point harness without a roll cage?
No. A 6-point harness needs anchor points above and behind the seat for the shoulder straps. Fit a roll cage or a properly engineered harness bar first. A 3-point bolt-in harness uses the standard seat belt anchor points and does not need a cage.
Which roll cage should I choose?
The JP Cages DIY Half Cage Kit at £295.62 suits a confident home fitter. The JP Hyundai I30N Half Cage at £461 and the SW Motorsports Bolt In Half Roll Cage at £480.83 are supplied ready to fit.
More help
Confirm your car is an N before ordering the subframe or a roll cage, and tell us which seat you are fitting if you need the mounting confirmed. Cameron works through the seat, frame and car combination together.
