Ford Mustang Fox Body and early SN95 bucket seat guide

Fox Body and early SN95: identify the year before choosing the frame

This guide covers the Fox Body Mustang from 1979 to 1993 and early SN95 models from 1994 to 1998. They are different generations within the wider application stated for Planted SB010. Match the actual car and seating side before selecting the upper fittings.

Garreth can compare the seat choices with the way you use the car. Send the exact model year and body, original market and steering arrangement. Include any earlier seat conversion or altered mounting area.

For the later restyle, use our 1999 to 2004 Mustang guide. Its Planted SB040 application is separate. Cameron can help assess the complete proposed assembly for the actual car.

Ford Mustang Third Gen on track with a helmeted driver
Ford Mustang GT Fox Body on track

Mounting

Start with the actual model year and the mounting area in the car. Previous repairs or seat changes need checking before a catalogue application is treated as a match. Include the retained hardware and buckle connection in the assessment.

Cameron can compare the assembled height with the driver seated. Check the door and centre area throughout the adjustment range. Include control access and rear-seat access where needed.

Planted SB010, physical sides and upper patterns

Planted lists SB010 for the Mustang from 1979 to 1998, covering the Fox Body and early SN95 application discussed here. The shop offers SB010PA as RHD Driver Side and SB010DR as RHD Passenger Side. State the physical side with the actual steering arrangement.

SB010DR is physical left and SB010PA is physical right. Planted calls those Driver/Left and Passenger/Right for its market. An LHD car therefore uses DR for its driver on the left, while a converted car needs its actual mounting arrangement confirmed.

The maker offers Standard and Alternate upper slider patterns. Standard includes the RECARO slider layout; Alternate replaces it with the Cobra and Scheel-Mann layout. Confirm the supplied pattern separately from the shop side dropdown.

Garreth can compare the exact seat and runner versions with the quotation. Itemise a lower assembly for each position being changed. Confirm the upper fittings and hardware at the same time.

OMP HC853, supplied reference and interface

The OMP shop order is HC853, described for the Mustang from 1979 to 1998. Its current choices are RHD Driver Side and RHD Passenger Side. Confirm the exact supplied reference and physical side against the actual car, especially for an import or conversion.

The listing states steel construction and a single frame, with 345 x 271 mm and 405 x 290 mm base patterns. Those figures describe the listed interface; they do not prove that every seat from a named brand connects directly. Side-mounted shells need their own assessed upper supports and fixings.

The shop description says bolts are not supplied. Have the full hardware and any runner arrangement itemised before ordering. Keep another OMP Mustang reference separate until its supplier application and package are confirmed.

Corbeau D828T, replacement frame or adapter

Corbeau D828T is the separate shop listing titled Mustang 78-98. Its required Sport Seat Position option selects Drivers Side or Passenger Side. Confirm the actual model year, physical side and steering arrangement with the supplied package.

Corbeau currently distinguishes complete replacement frames with double-locking sliders from adapters that use the factory runners. Those are different assemblies. The adapter description does not establish that the D828T shop order retains powered or other original adjustment.

The shop describes a route for suitable Corbeau base-mounted Sportline and Classic seats, rather than side-mounted shells. Ask Garreth to confirm the exact seat version and supplied frame or adapter. A 1978 catalogue label is not evidence that a Mustang II takes the Fox Body kit.

Other Mustang applications

For 1999 to 2004, follow the separate SB040 guide linked above. Planted lists SB170 for 1974 to 1978 and SB039 for 2005 to 2014. A broad Mustang name does not establish interchangeability between those applications.

The Fox Body and early SN95 share the named SB010 range, but each car still needs its mounting area and complete seat assembly assessed. No claim about identical floor geometry or retained original functions follows from that shared listing.

Runners and package contents

Sparco 0049306, Cobra Premium SUBFR07EL and the Endurance runner kit are upper options to assess with the selected seat and lower frame. Match both interfaces and include the added height. Cobra runner handle choices and Planted Narrow or Wide pattern distinctions need checking together.

Check the actual package before adding another set of rails. The Endurance Club Sport and Circuit listings state that sliders are included, as do the Type RR and Type AK listings. That does not establish the complete connection to the Mustang frame.

A fixed installation needs its own permitted lower connection. Cobra competition mounting guidance calls for direct side mounting without runners. Confirm the chosen seat instructions and intended event requirements before finalising that arrangement.

Side supports

The Sparco steel and Cobra steel side supports below are options to assess for a compatible side-mounted shell and lower assembly. Check the actual support profile, shell width, fixing positions and hardware together. A support’s own approval does not approve the complete installation.

Base-mounted seats use their specified base connection instead. Avoid buying supports or rails on the seat brand alone.

Fixed-back bucket seats

Cobra Monaco Pro is a steel-frame fixed-back seat with base and side mounting listed, including a 292 x 330 mm base pattern. Cobra Suzuka T Pro-Fit is a side-mounted shell. Select the method permitted for the exact seat and match its complete lower assembly.

OMP Champ-R and ARS-R, Mirco RS2 3D, Sparco Rev QRT and Evo QRT are side-mounted shells. The current listings state FIA 8855-1999 approval for these named competition seats and the two Cobra models above. Match the supplied label and version to the intended event.

Endurance Club Sport and Circuit use side mounting and are listed without FIA competition approval. Type RR is also listed as side mounted; confirm its actual supplied identity and approval, since a competition homologation is not established by the reviewed listing. Included sliders do not remove the need to check supports and lower fixings.

Garreth can compare hip and shoulder support in the intended trim. Cameron can check the preferred shell in its assembled position. A material or approval label alone cannot establish cabin clearance or the complete restraint installation.

Reclining sport seats

Sparco R100 Martini Racing, R333 and SPR list base mounting at 345 x 271 mm. Match the actual supplied seat and runner versions to the selected frame. Allow room for the backrest mechanism and controls.

Type JW lists a 345 x 280 mm base pattern; Type AK lists 405 x 280 mm. Those differ from the Sparco pattern and from the OMP frame dimensions quoted above. Have both interfaces checked instead of treating similar figures as interchangeable.

Corbeau RRS Leather Elite is a single seat, with a separate fitting assembly required for each seating position. The listing carries both 291 x 330 mm and 345 x 271 mm pattern attributes. Confirm the actual supplied version with the D828T or other selected lower route.

Cobra Misano Anniversary and Spec 2 list 291 x 330 mm base mounting. Cobra general mounting guidance gives 292 or 405 x 330 mm arrangements, so confirm the precise supplied seat and runner pattern. Choose the trim after checking support, rear access and usable recline.

Roll cages

The reviewed Mustang cage names do not establish a Fox Body or early SN95 application. Historic, Fastback, Notchback and 2015-on labels each need their actual supplier application checked. This guide does not recommend one of those cages without model-specific evidence.

Send Cameron the body and roof details with the intended use for a cage enquiry. Confirm the exact design and supplied sections before ordering. Installation documents and actual attachments are separate from the seat-frame application.

Harnesses

Assess the TRS Clubman, TRS Magnum, Takata Drift II and Drift III, and Schroth Profi 3×2 with the exact seat and anchorage arrangement. Strap count alone cannot establish suitable factory points, a cage tube or a harness-bar attachment. Use the selected belt maker’s instructions for anchorage strength and routing. Check its specified angles in the assembled position.

A six-point proposal needs a seat with a permitted crotch-strap route and the correct attachments. Do not treat those examples as direct matches for every recliner. Confirm the complete restraint installation for the actual seat and intended use.

Cameron can help check the belt path and buckle access, including the original arrangement where it is being retained. The seat and cage labels do not by themselves establish approval for the whole system.

What fits

Compare the vehicle application, seat interface and actual package before choosing the parts.

Route or seatApplication or methodInterface or contentsCheck before ordering
Fox Body / early SN951979 to 1993 / 1994 to 1998Separate generations within SB010 applicationExact model year, body, market and mounting area
Planted SB010Mustang 1979 to 1998Selected physical side and upper patternSeat, runner version and supplied bracket
Physical left / rightSB010DR / SB010PAShop RHD passenger / RHD driverActual steering arrangement and physical side
Standard / AlternateDifferent Planted upper patternsRECARO / Cobra and Scheel-MannSide dropdown does not specify the upper pattern
OMP HC853Shop application 1979 to 1998Single steel frame; bolts not suppliedSupplied reference, side and full hardware
OMP listed base patterns345 x 271 / 405 x 290 mmMatch actual seat and upper assemblyBrand name does not establish a direct connection
Corbeau D828TShop title 78-98; position option requiredComplete frame and factory adapter differExact seat, actual side and supplied package
Runners and supportsSeparate or package-supplied upper partsCheck both interfaces and added heightCobra competition guidance excludes runners
Cobra Monaco ProBase or side mounting292 x 330 mm listed base patternPermitted method for the actual version
Suzuka T / OMP / Mirco / QRTSide-mounted competition shellsCorrect supports and lower assemblyActual label, version and event requirements
Club Sport / Circuit / Type RRSide-mounted fixed-back examplesListings state included slidersApproval, supplied identity, supports and fixings
Sparco R100 Martini / R333 / SPRBase-mounted recliners345 x 271 mm listedRunner version, travel and control clearance
Type JW / Type AKBase-mounted recliners345 x 280 / 405 x 280 mmDifferent from the listed OMP and Sparco patterns
RRS Leather Elite / MisanoSingle seat / selected Cobra versionRRS dual attributes / Misano 291 x 330 mmActual supplied pattern and separate fitting assembly
Other years / cages / restraintsSeparate applications and installationsSB170 / SB040 / SB039 not interchangeableNo cage or anchorage approval from name or strap count

Manufacturer references: Planted physical-left application and physical-right application, Corbeau replacement and adapter arrangements, and Cobra mounting guidance. OMP details above follow the linked current shop listing; confirm the exact supplied reference and application.

Common questions

Fox Body models from 1979 to 1993 and early SN95 cars from 1994 to 1998; identify the actual model year, body and mounting area before selecting the package.

No. They are separate generations within the wider application stated for Planted SB010; a shared kit range does not prove every complete installation is identical.

Use the separate 1999 to 2004 Mustang guide linked in the introduction; its Planted SB040 application is separate from SB010.

SB010PA is physical right and the shop labels it RHD Driver Side; on an LHD car that is the passenger position.

SB010DR is physical left and the shop labels it RHD Passenger Side; on an LHD car that is the driver position.

Confirm Standard or Alternate separately with the exact runners; the shop dropdown selects the seating position.

Standard includes the RECARO slider pattern; Alternate substitutes the Cobra and Scheel-Mann layout. Confirm the actual supplied version and runner width.

The shop describes a single steel Mustang frame for 1979 to 1998 with 345 x 271 mm and 405 x 290 mm base patterns; confirm the supplied reference, physical side and actual seat interface.

The shop description says bolts are not supplied; have the correct hardware and any upper fittings itemised for the actual assembly.

Match the exact seat mounting method and both interfaces of any runner or support; a brand name alone cannot establish the complete connection.

The shop requires Drivers Side or Passenger Side; state the physical side and actual steering arrangement so the supplied package can be confirmed.

No. Corbeau distinguishes a replacement frame with sliders from an adapter using factory runners; confirm which assembly the actual shop order supplies.

That has not been established here; retaining an original powered frame is a different proposal from selecting a complete replacement assembly.

Do not infer that application from the short label; identify the actual model year and supplier kit. Planted lists the 1974 to 1978 application separately.

The shop describes D828T for suitable Corbeau base-mounted seats; a side-mounted shell needs its own confirmed supports and lower assembly.

Cobra Monaco Pro lists both, with a 292 x 330 mm base pattern; use the permitted method for the supplied version and confirm the lower connection.

The reviewed Evo QRT listing is side mounted; match suitable supports and the complete lower assembly rather than using a direct base-seat route.

Club Sport and Circuit state sliders are included; confirm the exact supplied package, side supports and both lower connections before adding separate rails.

No. Type JW lists 345 x 280 mm and Type AK lists 405 x 280 mm; neither figure should be substituted for another seat or frame pattern.

The reviewed listing is a single seat; confirm the exact version and specify the lower assembly separately for each position.

Specify the permitted complete fixed assembly first; removing runners changes the lower interface and installed position. Follow the selected seat and fitting instructions.

A Mustang name alone does not establish Fox Body or early SN95 fit; confirm the exact body, design, supplier application and installation documents.

No. Check the selected restraint instructions, actual anchors, routing and seated driver; strap count does not establish attachment suitability.

The exact seat needs a permitted crotch-strap route and suitable attachments; assess the complete seat and restraint arrangement rather than relying on the harness name.

More help

Send Garreth the exact model year and body with the original market, steering arrangement and physical side. Include the seat and runner references and photographs of the mounting area. Cameron can compare the actual proposed assembly with those details and the intended use.
