Ford Focus Mk1 bucket seat guide

Mk1 family, including ST170 and RS; check the exact kit application

The Focus Mk1 fitting choices here come from Sparco, OMP, Corbeau, RECARO, Planted and SW Motorsport. Select the vehicle kit with the exact seat and upper mounting parts in mind, checking the physical seating side and what the order supplies.

This guide covers the earlier Focus family, including ST170 and RS enquiries. Supplier year ranges differ: the shop describes the European Mk1 around 1998 to 2004, while Planted names a 2000 to 2007 application. Confirm the body, market and build details for the chosen kit instead of treating those dates as one universal range.

Send Garreth the car specification and seat model if a registration year leaves the generation unclear. Cameron can check the proposed assembly and driving position. Keep this installation separate from the following Focus generation when choosing the vehicle frame.

Ford Focus Mk1 on track with a helmeted driver
Ford Focus RS Mk1 on track

Mounting

The vehicle kit makes the lower connection to the Focus. Match the seat or runner fixing positions to that kit, adding suitable supports where the shell uses side mounting. Have the mounting areas inspected before installation, including any previous repairs.

Cameron can compare the complete installed height and cabin clearance with the driver in the required position. Allow room at the door, console and controls, and consider rear access on a three-door car. A low base or narrow seat description alone cannot establish the final driving position.

Sparco single and pair fitting kits

The single-frame listing offers 00499068DX as RHD driver and 00499068SX as RHD passenger, one frame per chosen position. Both list a 345 x 271 mm upper pattern. Sparco’s dated application table names DAW/DBW Focus three- and five-door cars from October 1998 and specifies its 00493 runner arrangement; confirm the current supplied kit and generation.

The 00499068-X2 listing supplies the stated driver and passenger frames in one order. Seats are separate. Check the actual runner and fixing contents before buying rails, because a pair of vehicle frames is not a pair of complete seat installations.

OMP HC816 fitting frame

The OMP HC816 shop choices are HC816D for RHD driver and HC816S for RHD passenger. Each covers one seating position, with 345 x 271 mm and 405 x 290 mm upper patterns listed. Compare the complete connection to the supplied seat and rails.

The wider pattern does not establish compatibility with every RECARO seat. A side-mounted shell needs suitable supports and a lower arrangement confirmed for that mounting method. Garreth can check the exact seat and parts list before you order.

Corbeau base-mounted seat route

The Corbeau CS16322 shop listing describes the 1998 to 2004 Mk1, with driver or passenger and slide or tilting selections. It is priced per position and describes double-locking runners with the kit. Confirm the actual frame or adaptation arrangement supplied for your car.

Corbeau specifies its base-mounted reclining and classic seats for these subframes and excludes side-mounted seats. Its current general application table has a Focus 2000 to 2009 entry, which does not by itself confirm CS16322 for every earlier car or market. Check the exact kit before adding separate rails.

RECARO body and physical-side checks

The RECARO shop listing uses 865716 and offers both RHD seating positions, describing cars built before September 2004. RECARO’s linked table identifies 86.57.16 in the physical-left column for DAW, DBW, DFW and DNW bodies, with no right-side reference shown in that row. Have the actual supplied side confirmed, especially for an RHD driver position.

Match the exact RECARO seat version to the body and frame documentation. The shop describes sliding runners in the package, but the table alone does not prove those contents or approval for every RS, ST170 or Sportster CS combination. A side-mounted competition shell needs a separately confirmed mounting route. The dated 2018 RECARO table marked this frame discontinued, while the linked table still lists its reference; have current supply and the actual package confirmed.

Planted 2000 to 2007 application

Planted names the Focus 2000 to 2007 and has separate physical-left and physical-right brackets. The shop labels SB038PA as RHD driver, on the right, and SB038DR as RHD passenger, on the left. Confirm that the actual car and market match this application before ordering.

Planted offers Standard and Alternate slider patterns: Standard includes the RECARO pattern, while Alternate substitutes the Cobra and Scheel-Mann pattern. Its maker pages use driver/left and passenger/right labels for their market. Use physical side and the exact rail pattern when checking the supplied bracket.

SW Mk1, ST170 and RS listings

The SW Mk1 listing supplies one selected-side lower base, with supports, sliders, bolts and harness eyebolts separate unless chosen with the order. The support add-ons offer 8 or 10 mm seat-bolt choices. Match these to the actual shell, and compare the complete fixing arrangement because the 345 mm width attribute gives only one dimension.

The shop identifies SW-SM-0048 as RHD driver and SW-SM-0050 as RHD passenger; SW’s current Mk1 page instead labels the driver SM-0049 and passenger SM-0050. Ask Garreth to confirm the current supplier code and physical side before ordering. The maker’s broader category dates do not establish fit for every Focus generation or market.

The separate ST170 and RS Mk1 listings repeat the shop’s 0048/0050 references. They are model-specific order listings for the same stated family, with the same code discrepancy to resolve. Confirm the exact car and supplied assembly for either order.

Sliding runners and package contents

Sparco 0049306, Cobra Premium SUBFR07EL and Endurance runners are separate options to assess with the selected lower assembly and seat. Compare both fixing interfaces and the added height; Cobra also has seat-dependent handle configurations. For competition use, follow the actual seat maker and event requirements, including Cobra’s specified use of side mounts without runners.

Check package contents first: the Corbeau frame describes runners, and the Club Sport and Type RR seat listings describe sliders with the seat. Avoid buying a second set where the confirmed order already supplies the rails you need.

Side supports

Sparco steel side supports are an option for a compatible side-mounted shell and suitable lower assembly. Check shell width, fixing positions and specified hardware together. They do not turn a Corbeau base-mounted subframe into a side-mount route.

Fixed-back bucket seats

Sparco Sprint and Cobra Monaco Pro list base and side mounting, with different base patterns: 345 x 271 mm for Sprint and 292 x 330 mm for Monaco Pro. Choose the method for the actual supplied seat and a suitable lower assembly.

OMP TRS-E Sky is a steel-frame seat with base and side mounting and a 345 x 270 mm base pattern. OMP Champ-R, Mirco RTS-2 Velour, Mirco RS1 3D, Sabelt GT3 and Sparco Evo L QRT are side-mounted shell choices, requiring supports matched to the actual seat.

Corbeau Sprint X System 1 and Pro Series X System 1 list FIA 8855-1999 approval; System 1 identifies the seat variant. Confirm the supplied seat label and current event requirements separately from the frame and runners.

Endurance Club Sport and Auto Style Type RR are the other side-mounted options below. The Club Sport description states no FIA approval, while the Type RR needs its supplied approval and intended-use details checked. Cameron can help compare driver support, shell width and headroom in the Focus.

Reclining sport seats

Sparco R100, R500 Fabric, R333 and SPR list 345 x 271 mm base patterns; Auto Style JW and MS instead use 345 x 280 mm. Compare both dimensions with the chosen frame and rails, allowing room for backrest travel and the controls.

Cobra Daytona is a steel-frame recliner whose shop base pattern is 291 x 330 mm. Cobra’s general mounting guidance describes 292 or 405 x 330 mm seat patterns, so confirm the supplied seat and runner configuration. A matching frame brand or one shared dimension cannot establish the complete connection.

RECARO Sportster CS and its heated version list 405 x 290 mm base fixing. Check the actual seat version, frame, physical side and body application together. The matching RECARO name or an OMP wider pattern does not establish the whole installation.

The Corbeau RRS product below supplies two standard-base reclining seats in black vinyl, with vehicle frames separate. Its attributes show two base patterns, so confirm the actual version and matched Corbeau Mk1 kit. One RRS pair order supplies two seats, while a single-side Corbeau frame order covers one position.

Roll cages

The cage application is narrower than a general Focus Mk1 heading. Check the body, roof and selected assembly before ordering, then plan seat position and restraint routing with the installer. Approval still depends on the required installation and event documentation.

Safety Devices roof and body applications

Safety Devices F113 is the 1998 to 2004 three-door family for a car with a sunroof; F114 is the corresponding no-sunroof family. The rear listings below offer different diagonals and harness-bar arrangements. Check the exact rear configuration and compatible front or door-bar sections if you need a fuller assembly.

The maker describes a folded rear seat and minor backstay trim work for these layouts. F114 adds lower backstays and cannot use standard door cards. Those interior requirements need planning alongside the seat installation.

F111, RBF111 6SSX, is the full CDS weld-in kit for a 1998 to 2004 three-door without a sunroof. Safety Devices lists Motorsport UK/FIA homologation for these families. Confirm the actual configuration, installation and current event acceptance.

OMP and Sparco bolt-in cage options

OMP AB/105P/259H is the shop’s 1998 to 2004 three-door, ten-point bolt-in listing. Its description requires welded feet brackets and cutting or welding of connecting parts, with bolt contents needing confirmation. Arrange the complete installation from the code-specific instructions; bolt-in does not mean the job requires no welding.

Sparco 00723068 is the six-point bolt-in listing for the Mk1 from October 1998 to 2004. Confirm the exact body and current installation and approval documents before ordering. A six-point description alone does not establish eligibility for every class.

Custom Cages CDS and T45 kits

Custom Cages FO/00C is the CDS multipoint weld-in kit, labelled FIA Compliant by the maker. FO/00T is the International T45 kit, labelled FIA Certificated. Follow the installation and documentation process for the actual kit and intended event.

Both maker titles contain Mk1 and a ‘>05’ date label, so have the exact body and build application confirmed. That wording should not be treated as permission to fit a different Focus generation.

Harnesses

Assess the TRS Clubman, TRS Magnum, Takata Drift II and Drift III, and Schroth Profi 3×2 with the exact seat and proposed anchorage arrangement. Strap count does not establish suitable factory points, cage tubes or harness-bar attachments. Follow the selected belt maker’s instructions for strength, routing and belt angles.

Cameron can help check the route through the seat and the required lap, shoulder and any crotch-strap attachments. Confirm the belt’s current approval and intended use separately from the cage and seat. Having a cage does not complete the restraint installation.

What fits

Compare the complete vehicle and seat connection, supplied parts and intended use when choosing a route.

Route or seatApplication or methodInterface or contentsCheck before ordering
Sparco single / pair00499068DX/SX / 00499068-X2345 x 271 mm; check rails and fixingsOne selected frame / stated driver and passenger pair
OMP HC816HC816D driver / HC816S passenger345 x 271 or 405 x 290 mm shop patternsExact seat and rails; no universal RECARO fit
Corbeau CS16322Base-mounted Corbeau recliners/classic seatsShop describes double-locking runnersActual Mk1 application/package; excludes side mounts
RECARO 865716Maker86.57.16 physical-left rowDAW/DBW/DFW/DNW; exact seat versionNo right-side code shown; confirm actual side and body
Planted SB038Maker2000-2007; separate physical sidesStandard / Alternate slider-pattern optionsExact vehicle/market; RHDdriver shopPA,passengerDR
SW Mk1 / ST170 / RS Mk1Shop0048 driver /0050 passengerMakerSM-0049driver /SM-0050passengerResolve supplier code; supports/sliders/fixings separate
Sparco Sprint / Cobra Monaco ProBoth list base and side mounting345 x 271 /292 x 330 mm base patternsChoose actual mounting method and lower connection
OMP TRS-E SkySteel frame,base and side mounting345 x 270 mm base patternNot a fibreglass side-only shell
Corbeau Sprint X / Pro Series XSide-mounted System1 variantsShop FIA8855-1999 listingSystem1 identifies variant; check seat label/event
Sparco recliners / Auto Style JW and MSBase mounting345 x 271 /345 x 280 mm respectivelyDifferent fixing patterns; full installed clearance
Cobra DaytonaSteel-frame reclinerShop291 x330;maker292/405 x330 guidanceExact supplied seat and runner configuration
RECARO Sportster CS / heatedBase-mounted seat versions405 x290 mm shop patternBody,physical side and complete kit documentation
Corbeau RRS pairTwo standard-base reclining seatsVehicle frames separateExact version and frames for both seating positions
Safety Devices F113 / F114 / F111Withsunroof /without /fullweld-inNamed1998-2004 three-door applicationsRoof,door cards,selected sections and installation
OMP / Sparco cagesAB/105P/259H /00723068Ten-point /six-point shop descriptionsOMP weldedfeet/cutandweldparts;exactdocs/event
Custom Cages FO/00C /FO/00TCDSCompliant /T45CertificatedMultipoint weld-in kitsConfirm Mk1 body/year wording and event documents

Common questions

Check each supplier application separately, including body and market; Planted names 2000 to 2007 and does not establish universal European Mk1 fit.

Sparco, OMP, Corbeau, RECARO, Planted and SW are covered, including Sparco single and pair orders and the SW trim-specific listings.

The shop labels 00499068DX as RHD driver and 00499068SX as RHD passenger; confirm the physical side and actual supplied kit.

It supplies the stated driver and passenger vehicle frames, with seats separate; check runner and fixing contents before ordering other parts.

Compare the exact seat, rails and lower assembly; a 405 x 290 mm pattern alone does not establish universal RECARO compatibility.

Corbeau excludes side-mounted seats from these subframes; choose a separately confirmed lower assembly and supports intended for that shell.

The shop describes runners with the frame; confirm the actual Mk1 package before buying an extra set.

The linked maker table identifies 86.57.16 on the left and shows no right-side reference in that row, so confirm the supplied side. Confirm current supply because the older table marked this reference discontinued.

Match the exact seat version, body and physical side to the current kit documentation; the shared RECARO name alone cannot establish the complete fit.

The shop labels SB038PA as RHD driver on the right and SB038DR as RHD passenger on the left; confirm the car and supplied physical side.

Confirm the exact vehicle and market before ordering; the maker's date range alone does not establish that wider application.

Standard includes the RECARO slider pattern; Alternate substitutes the Cobra and Scheel-Mann pattern, so choose the configuration for the actual rails.

The shop says SW-SM-0048 while the current maker page says SM-0049; have SW confirm the current supplied reference and physical side.

Their descriptions repeat the same shop 0048/0050 family; the supplier-code discrepancy and exact vehicle checks still apply to both.

Match the optional 8 or 10 mm seat-bolt support choice to the actual shell and complete lower assembly.

Check the confirmed package first; the Corbeau frame, Club Sport and Type RR listings already describe runners or sliders with their orders.

Sprint lists 345 x 271 mm and Monaco Pro 292 x 330 mm, although both describe base and side mounting.

Its listing describes a steel frame, base and side mounting, and a 345 x 270 mm base pattern.

System 1 identifies the seat variant; the Sprint X and Pro Series X listings here state FIA 8855-1999 approval.

Both list 345 x 280 mm, which differs from 345 x 271 mm; check the complete connection for the selected seat.

It is a steel-frame recliner listed at 291 x 330 mm; confirm the supplied seat and rail configuration against Cobra's mounting guidance.

F113 names the three-door with a sunroof, while F114 names the three-door without one; select the exact rear configuration and required related sections.

Its application is the 1998 to 2004 three-door without a sunroof; confirm the exact car and full weld-in installation.

The shop description includes welded feet brackets and cutting or welding of connecting parts; arrange the installation from the exact cage instructions.

The maker labels FO/00C CDS FIA Compliant and FO/00T T45 FIA Certificated; confirm the required installation and event documentation.

Use the chosen belt maker's instructions for the actual seat and car, including attachment strength, routing and angles; strap count alone cannot establish a suitable installation.

More help

Send Garreth the Focus build details, body and roof type, market and physical seating side, together with the exact seat model. Include whether you need one seat or a pair and any competition requirements. Cameron can check the proposed kit, upper mounting parts and driving position against that specification.
