Lotus Exige Bucket Seat and Fitting Guide
Choose the seat around your Exige’s actual mountings
A bucket seat change in an Exige starts with the original mounting arrangement and the position you want in the car. A runner-mounted Tillett assembly, a fixed bracket system and a Reverie conversion of original Lotus hardware involve different parts. Match that route with the exact shell before ordering.
Garreth would try the seat for support and access in the trim you intend to use. Cameron would identify the Exige variant, its existing subframe and the physical seating side. Bring photographs of the current mountings so we can match the parts to the car.
At a glance
- Identify S1, S2 or V6/S3, the build/VIN details, steering side and original seat/subframe.
- Tillett EBR uses identified original runners in its pre-2017 application; EBS is a separate fixed U-channel system.
- Later Tillett arrangements need the appropriate current lower fittings and their own vehicle confirmation.
- Reverie Mulsanne C/XC/XRC and Mulsanne B use different conversion packages. Match the seat, original subframe and steering/physical side.
- Reverie R01SI0115 has exact shell and seating-side conditions. A generic side mount is a different component.
- A six-point Schroth harness example is shown for a separately matched seat, belt route and anchor arrangement.
Identify the existing seat and subframe
Record the generation, build details and steering side with the enquiry, with photographs of the lower mountings and any earlier conversion. For a Reverie route, the original Lotus or GM subframe reference can determine the conversion parts required.
A model-year description gives us a starting point; include the VIN and the actual hardware as well.
Cameron would compare the driver’s current position with the change wanted. Include the travel needed by other drivers and the clothing used in the car. We would trial the proposed shell and lower assembly together.
Retain identified original runners with Tillett EBR
EBR brackets connect the named Tillett shells to original runners in the maker’s pre-2017 application, which Tillett ties to VIN serial boundary 1457. Confirm that boundary and the actual runner arrangement against the car before choosing the set.
The maker specifies 3mm steel and a 2° draw angle to match the seat side. Its listed families include B6 Screamer, selected B6XL/B7 versions and B8-43/B9-43. Match the full shell reference and edge option with the current kit.
Tillett’s hardware bulletin specifies an additional washer beneath the rearmost fixings on the named runner brackets. Confirm the current EBR brackets and rear-fixing package actually supplied. The original runners are part of this route. Add separate components only after matching what the complete package requires.
Choose EBS when specifying a fixed Tillett assembly
EBS uses a U-channel and upright bracket system for a fixed installation. The current application names pre-2017 cars, the VIN serial boundary 1457 and 383mm front-to-rear mounting-hole spacing. Confirm the actual floor and supplied version.
Its position can be set at 10mm intervals, then the assembly is secured in the chosen position. This adjustment during fitting differs from sliding the seat on an operating runner.
Specify the exact shell and physical side with the current EBS package. The maker gives seat-version and belt-fitting conditions, including different B10XL options. We would confirm those details and the supplied U-channel revision before recommending the combination.
Tillett’s published recall covers EBS U-channels sold from 2018 to 2023. If using a kit from that period, follow the maker’s recall guidance and confirm the required replacement with Tillett before installation. Match the current supplied channel and hardware to the selected assembly.
Specify a later-car Tillett arrangement separately
Tillett also describes EBR used above ERAIL as a fixed assembly, with the lower parts and their own application. Its later original-runner bracket is EBR17+. Give us the exact car, seat and adjustment wanted so the appropriate current arrangement can be confirmed.
Keep the lower rail, side bracket and hardware together in that specification.
A shared Exige name does not establish the complete assembly across generations. We would match the physical mountings and current instruction before recommending a later-car package. Trial the selected arrangement for the driver’s usable position.
Match the Mulsanne C/XC/XRC conversion to original hardware
This Reverie route is for the named narrow Mulsanne C, XC and XRC shells on an identified original subframe. The driver conversion and passenger A340 subframe package are different. Match the retained hardware and the intended belt arrangement before ordering.
Reverie identifies R01SI0039 as RHD driver and R01SI0053 as LHD driver. Its passenger packages are R01SI0063 for RHD and R01SI0064 for LHD. Confirm the manufacturer code and physical seating side with us when selecting the current shop option.
The current detail includes Exige S3/V6 through 2019, while the dedicated instructions describe specific earlier subframes and VIN conditions. Send the actual build and subframe reference. Cameron would match the current brackets, crossmember and retained or supplied rails as one assembly. A 2020 or 2021 car needs its own current confirmation.
-
From £86.93 Incl. VATFrom £72.44 Excl. VATPayPal CreditSelect options This product has multiple variants. The options may be chosen on the product page
Use the separate Mulsanne B conversion specification
Mulsanne B uses its own conversion components. The maker’s collection and brochure identify R01SI0081 as RHD driver and R01SI0083 as LHD driver; R01SI0085 and R01SI0086 are the separate RHD and LHD passenger packages. Confirm the current full reference, including any revision suffix, with the original subframe.
Give us the seat and physical side before selecting an option on the listing.
The fitting package can involve conversion brackets, a crossmember, spacer components and retained original fasteners, so confirm the current spacer specification and whether R01SI0087 is required separately. A V6 enquiry also needs the actual year and original mounting arrangement matched to the current instruction.
-
From £90.30 Incl. VATFrom £75.25 Excl. VATPayPal CreditSelect options This product has multiple variants. The options may be chosen on the product page
Match R01SI0115 to its named Super Sports shell
For the Lotus-specific CNC bracket pair R01SI0115, Reverie names FIA twin-skin R01SI0091 for both seating positions and single-skin R01SI0106 for the driver side only. Give the full shell reference and actual vehicle details when asking about this route.
The single-skin driver condition must stay with that particular shell and assembly.
Match the lower connection and current fastener package to the floor. The universal R01SI0111 mounts and the steel R01SI6215 brackets have their own applications. We would confirm a different Super Sports shell, including a non-FIA version, separately.
Compare the Tillett shell and intended restraint use
The standard B6 Screamer GRP is the competition-oriented choice here, with FIA 8855-1999 homologation listed for its 400mm and 440mm outer leg-width options. Match the exact supplied label and the requirements of the intended event. The current seat needs its specified side-mount assembly.
The B8 GRP offers 430mm edges-off and 445mm edges-on versions. Its swept-away hip area accommodates the standard three-point belt or a race harness subject to the installation. This is a Road and Track shell with no FIA homologation.
The B10 has cut-away sides intended to accommodate standard belt use and ease access. Our standard listing offers GRP or carbon/GRP with panel options. The current EBS application names B10, but its exact version and supplied assembly still need matching.
Garreth would try the cushion and shell shape before choosing the finish. Compare how you get across the bolster as well as the support once seated. Choose the width and trim together.
-
From £1,234.36 Incl. VATFrom £1,028.63 Excl. VATPayPal CreditKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
-
From £1,151.39 Incl. VATFrom £959.49 Excl. VATPayPal CreditKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
-
From £1,151.39 Incl. VATFrom £959.49 Excl. VATPayPal CreditKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
Choose the exact Reverie shell before its conversion parts
The Mulsanne C and narrow XC are different shell shapes within Reverie’s conversion-system discussion. Use the complete seat reference when choosing the original-subframe adapter, and confirm a wider or differently mounted version separately.
The Super Sports FIA card shown here is R01SI0106, the single-skin shell. With the Lotus R01SI0115 assembly discussed above, the maker’s instruction restricts that shell to the driver side. A passenger enquiry requires the appropriate named shell and fitting package.
Try the intended trim and check the harness-opening position with the driver. We would confirm the exact current seat label and component combination. A carbon finish or the family name cannot establish the fitting or homologation of another version.
-
From £1,503.60 Incl. VATFrom £1,253.00 Excl. VATPayPal CreditKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
Discuss the Corbeau LE seat with the original brackets
The Corbeau LE-Pro is another Lotus-seat route to discuss with the actual original brackets. Corbeau describes an S1/S2 replacement-seat family. Give us the exact current shell, trim and car details so the mounting arrangement can be matched.
Garreth would compare the LE-Pro bolster support and access with the Tillett and Reverie shapes. Specify the current shell, trim and retained brackets with the enquiry. The fitting package depends on the original mounting arrangement.
The LE-Driver is a separate side-mounted shell. Match its complete connection to the car before choosing the lower fittings. An LE-Pro replacement-seat statement does not establish that assembly.
-
From £672.00 Incl. VATFrom £560.00 Excl. VATPayPal CreditKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
Compare B6 Screamer and B8 widths at one scale
The B6 Screamer and B8 drawings distinguish external leg width from internal hip width. The standard B6 Screamer has 340mm internal hip width; the B8 has 365mm. The bars show both edge options at a shared scale.
These widths describe the shells at different measurement locations.
The standard B6 Screamer drawing gives 430mm external shoulder width, 695mm projected length and 810mm overall height. The B8 gives 445mm shoulder width, 760mm projected length and 860mm overall height. Cameron would check the selected shell at its installed angle with the actual lower assembly. Floor-hole spacing is a separate measurement.
See the original B6 Screamer and XL drawing and B8 drawing for the measurement locations. The bars use standard B6 Screamer dimensions; an XL seat needs its own dimensions. Confirm exact B10, Reverie or Corbeau measurements for the selected version before using them for a clearance decision.
Choose the adjustment as part of the assembly
The EBR original-runner route retains identified car runners. EBS position is set through its fixed bracket system. EBR with ERAIL is another fixed arrangement with its own lower components.
With a Reverie conversion, establish which original subframe and adjustment mechanism are retained and which parts are replaced.
Cameron would check the complete travel or fixed position against the driver’s reach. Include the steering wheel, pedals, buckle and controls in that trial. Check the clearance through the adjustment actually needed.
Assess a recliner as a complete fitting enquiry
If backrest movement is the priority, send the exact recliner and car details for a separate fitting enquiry. Its mechanism and controls need room as well as the shell. We would check the lower connection and usable movement before recommending a package.
The named fixed-shell systems above do not establish a universal recliner assembly.
Match the belt route to the seat and its mountings
Choose the intended restraint before finalising the fittings. The B6 Screamer information recommends a five- or six-point race harness; B8 and B10 information describes standard-belt or harness use. Follow the exact seat and restraint instructions with the actual anchor arrangement.
Reverie’s instructions distinguish original subframes from the specific conversion or replacement parts used with harnesses.
Show the existing belt mountings and any proposed harness bar or cage with the enquiry. We would match the shoulder and lap routing, buckle position and any lower straps to the seated driver. A harness slot or a bracket listing alone cannot specify the complete restraint installation.
The Schroth Profi 3×2 six-point card is an example to discuss for a race-harness build once the seat, belt routing and anchors are specified.
- Original belt: confirm the selected shell, buckle position and mounting hardware together.
- Harness: identify the exact seat and anchor arrangement before choosing the harness product.
- Existing conversion: photograph the actual mountings so the required components can be checked.
-
From £444.01 Incl. VATFrom £370.01 Excl. VATPayPal CreditKlarna ReadySelect options This product has multiple variants. The options may be chosen on the product page
Bring the car, shell and fitting details together
Send the Exige’s build/VIN details, steering side and physical seating position with the complete seat reference. Include the edge and panel options where relevant. Add the original subframe reference and photographs of any earlier conversion.
We can then match the current package and the parts it retains from the car.
Trial the complete assembly with the driver for position and clearance. If a lower position is the aim, compare that trial with the original measurement. The shell angle, cushion and every fitting beneath it affect the final result.
Common questions
What details identify the correct Exige kit?
Give the generation, build/VIN details, steering side and physical seating position. Include photographs and the original subframe reference where available. An earlier conversion needs its own parts check.
What is the difference between EBR and EBS?
EBR has an application above identified pre-2017 original runners. EBS uses a fixed U-channel assembly whose position is set during fitting. Confirm the exact current bracket version, shell and vehicle conditions for either route.
How do I choose a kit for a later Exige?
Send the actual car and mounting details with the seat and adjustment wanted. Later Tillett original-runner and fixed arrangements involve different components. Match the current lower assembly before ordering.
Which Reverie C/XC/XRC code is for each side?
Reverie identifies R01SI0039 as RHD driver and R01SI0053 as LHD driver. Its passenger packages are R01SI0063 for RHD and R01SI0064 for LHD. Confirm the full manufacturer reference and physical seating side with us when selecting the current shop option.
Does Mulsanne B use the same conversion kit?
It has its own components and current revision to match. The maker collection identifies R01SI0081/R01SI0083 as RHD/LHD driver, with R01SI0085/R01SI0086 passenger packages. Confirm the complete reference, original subframe and supplied spacer set.
Can R01SI0106 go on the passenger side with 0115?
The maker’s single-skin 0106 instruction for the Lotus 0115 assembly is driver-side only. A passenger installation requires the appropriate named shell and fitting package. Confirm the actual car and current components before ordering.
Does an LE-Driver fit like an LE-Pro?
Treat it as a separate mounting enquiry. The LE-Driver uses its own side-mount interface, so its complete connection to the car needs specifying. An LE-Pro replacement-seat statement does not establish that assembly.
What do the scale bars measure?
They compare standard B6 Screamer and B8 external leg widths and internal hip widths. They do not show the Exige floor pattern or confirmed cabin clearance. Check the selected version and trim in the car.
How much lower will a bucket seat sit?
The shell, cushion, angle and lower fittings determine the finished position. Trial the complete assembly with the driver. A bracket code alone cannot give a height reduction.
Can I choose a reclining seat?
Send the exact recliner for a complete fitting enquiry. Its lower connection, controls and usable backrest movement need checking together. We would establish that package before recommending it.
Does a harness slot confirm the belt installation?
The seat, restraint and actual anchor arrangement must be matched together. Follow the relevant component instructions with the driver seated. Include any existing harness bar or cage in the enquiry.
Are runners and all fasteners supplied?
Contents depend on the specific route and revision. Some systems retain original hardware; others use a different lower assembly. Confirm the complete supplied and retained parts list before adding individual fittings.
Garreth’s top tip
Garreth would try the seat for support and access in its intended trim before choosing the finish. Keep the belt arrangement and adjustment wanted in that decision. Those choices help us match the fitting route to the way the car will be used.
Cameron’s fitting view
Cameron would identify the actual original subframe and physical side, then match the complete seat and fitting references. Confirm the current supplied and retained parts together. Trial the assembly with the driver before settling its position and clearance.
Plan your Lotus Exige seat change
Drop us an email or click to open a chat through our contact page. For a full seat and fitting-kit recommendation, call 0115 647 8650.
