BMW F20 and F21 bucket seat guide, including the M135i and M140i

2011 to 2019

An F21 owner can find a frame under F21, F20/F21 or M140i, depending on the listing. Garreth's starting point is the body code and the seat you want to use. Cameron then checks the complete mounting assembly, because those three search labels do not establish that the parts are interchangeable.

BMW identifies the five-door M140i as F20 and the three-door as F21. Cobra and SW Motorsport have named F20/F21 applications, while some Planted, PCI and RECARO products use the engine badge. Each route has its own side codes and seat requirements, so keep those details with the part you choose.

Start with the vehicle base, then check the runner or fixed support arrangement and the seat fixing points. A matching seat bolt pattern only answers one part of that assembly. Your driving position and cabin clearance need checking with the actual seat in the car.

BMW BMW F20/F21 Including M135i M340 on track with a helmeted driver
The F20 M135i on a trackday

Fitting frames, runners and supports

Cobra F20/F21 frames and the SW base

Cobra's application table groups F20/F21 for 2012 to 2019 under SU-BMW-F20-01L and SU-BMW-F20-01R. We list F20 and F21 separately. Each listing has driver, passenger and pair choices. Match the supplied maker code and physical side when ordering through either listing.

Cobra's FRM-06 drawings show runner assemblies at 292 mm and 405 mm spacing, with different handles and a seat-dependent belt bracket. The shop's 291 mm by 330 mm attribute describes a mounting pattern, so the supplied configuration still needs confirming against your exact seat. The maker table also specifies separate Nogaro side mounts for that seat family.

The SW Motorsport F20/F21 listing gives SW-SM-0028 as its part reference and offers the base for either side. Choose the physical side with the order. Side mounts or a slider assembly attach above the base; the listing says these parts and harness eyebolts are separate. Check the chosen runner pattern, supports and hardware as one assembly.

The Planted M140i listing

We list the Planted bracket as SB139-1. SB139DR-M140i is shown as RHD passenger side and SB139PA-M140i as RHD driver side. Planted's application guide names its SB139 family against a 2008 to 2011 1 Series. We need the actual supplied F20 or F21 application confirmed before recommending this M140i-labelled bracket for your car.

Send the exact seat model with the body code so the complete lower and upper connections can be checked together. The installed position depends on that assembly, including the runner and seat-support arrangement.

PCI sliding mounts and RECARO configurations

The PCI M140i listing has separate left and right shop part numbers. Its left option is RHD passenger side and its right option is RHD driver side. PCI's standard S1 system includes its S1 sliders and SM-SIDE-S1 supports, so check the supplied package before buying another runner or support kit. The exact F20/F21 application and seat interface for this listing still need confirmation.

RECARO's application table gives F20 type 1K4 the left/right codes 69.02.19 and 69.02.29. F21 type 1K2 uses 69.03.19 and 69.03.29. Both shop listings below currently have 69.02-based variants, so an F21 enquiry needs the correct 69.03 configuration confirmed before an order is placed.

Match the exact seat column as well as the frame number. RECARO marks particular Sportster CS, Cross Sportster CS and Ergomed E/ES SAB combinations against the F20/F21 rows. The F30/F31 rows have different CS/SAB entries. A generic RECARO name or a separate Pole Position card does not establish the required combination.

Separate side mounts

Match a side-mounted shell's fixing points to the chosen supports and lower assembly. The Sparco steel supports are a separate catalogue option to check against the required pattern and hardware; other kit makers may specify their own supports.

Send the body code and physical side with the part number. The Planted DR option above is RHD passenger side, while the SW DR option is RHD driver side. Use each listing's explicit side selection instead of applying one suffix rule across brands.

Fixed shells

Match the exact shell version's side-fixing pattern to the selected supports and lower frame.

The Cobra Monaco Pro and Sparco Sprint also belong with the fixed shells. Their current listings include base and side mounting choices. The stated base patterns differ, so use the actual seat label and fixing points when choosing the runner and lower frame. Shoulder and base clearance need checking in the car.

Reclining seats

The RECARO Speed and Sportster CS, Sparco R333 and R500, Cobra Daytona and Corbeau Sportline RRS are the reclining choices shown here. Their current base-pattern descriptions differ: the RECARO entries use 405 mm by 290 mm, while the Sparco entries use 345 mm by 271 mm. The RRS listing has more than one pattern, so confirm the supplied version with the order.

Cobra's own application and assembly documents provide a route to check for its recliners, including the runner configuration. For a Sportster CS, keep the exact seat version with the correct F20 or F21 frame code when assessing the assembly, backrest adjustment and access in the car.

Garreth's top tip

I'd start with the named Cobra or SW F20/F21 application and work upwards to the seat. Settle the complete frame, runner and support order before choosing extra fitting parts. With Cobra, that includes the supplied FRM-06 configuration. Cameron can then check a specific assembly against the seat and the car.

For a RECARO Sportster CS, keep the exact seat version with the body code from the beginning. An F21 owner needs the 69.03 route checked, even if a product title also says M140i. Drop us an email or click to open a chat with those details.

Harness choices

The harness listings include the TRS Clubman and Magnum ranges, Takata Drift II and III, and the Schroth Profi 3×2. Choose the actual belt version with the seat and intended use. Check its current label and manufacturer instructions before treating a product name as a complete restraint recommendation.

The car's standard belt also needs checking with the chosen seat and buckle arrangement. A frame hole, buckle tab or cage listing does not establish a suitable harness anchorage. Send the proposed seat and restraint details so the installation can be checked as a whole.

Cameron's fitting view

Check the exact seat model, selected belt and actual anchorage arrangement against the belt maker's instructions and any event requirements. The application check for a seat frame does not also approve the restraint installation.

A belt that carries a dated approval needs its own label checked for the intended event. Condition and the manufacturer's replacement instructions still matter for other belts. Cameron can help identify the information needed from the selected products before you order.

Roll cages by body

The shop lists separate SW Motorsport F20 and F21 half cages and Basic MSUK full-cage products. The F20 entries use the maker's four-door wording for the five-door hatch body. The F21 entries name the three-door. Choose by the exact body and product code instead of the shared F20/F21 label.

Confirm the selected cage configuration, supplied installation parts and intended use with the manufacturer. Include restraint anchorage and seat clearance in that assessment; a half-cage or full-cage title does not settle those requirements.

Mounting checks at a glance

Keep the vehicle application, physical side and exact seat version with the complete assembly when checking installed position and cabin clearance.

RoutePart referenceAssembly check
Cobra F20 and F21 listingsSU-BMW-F20-01L/R; FRM-06 maker referencesConfirm the supplied side, 292/405 runner configuration and exact seat pattern; Nogaro has specified side mounts.
SW F20/F21 baseMaker SM-0028; shop SW-SM-0028-F20-DR/PAMatch the chosen supports or runner to the base and seat; confirm hardware and quantities.
Planted M140i listingSB139DR-M140i / SB139PA-M140iConfirm the actual F20/F21 application and full assembly; the maker's SB139 row names an earlier 1 Series period.
PCI M140i sliding listingPCI-BMW-1-Series-L/R-M140iConfirm actual maker application, side and seat interface; check the included S1 slider/support package.
RECARO F20Maker 69.02.19 left / 69.02.29 rightMatch type 1K4 and the exact seat column; check adapters and runner requirements.
RECARO F21Maker 69.03.19 left / 69.03.29 rightConfirm type 1K2 configuration. The two displayed RECARO listings have 69.02-based variants.
Fixed shells with base optionsMonaco Pro MNP-S; Sprint BRR0003B0 listingsConfirm the actual seat revision and base or side fixing points; both are fixed shells.

Questions about fitting seats in an F20 or F21

Can I find a frame using the F21 chassis code?

There are separately named Cobra F21 and combined SW F20/F21 entries as well as M140i-labelled products. Send the body code and seat model so we can check which complete fitting route is suitable.

Does an M140i listing automatically cover both bodies?

The M140i badge appears on F20 and F21 cars. The mounting application still needs matching to the actual body and supplied part code. RECARO's different F20 and F21 families are one example of why the badge alone does not settle the order.

Do Cobra frames need a separate runner kit?

The FRM-06 assembly drawings show premium runner configurations with different handles and seat-dependent parts. Confirm which configuration comes with the selected listing and seat before adding another runner kit.

What goes above the SW Motorsport base?

A suitable side-support or slider arrangement connects the seat to the base. Match both sets of fixing points and confirm the supplied hardware. The maker's general slider description does not establish that every runner and seat combination will fit.

Which Planted option is the RHD driver side?

SB139PA-M140i is the current RHD driver-side option. SB139DR-M140i is RHD passenger side. Use those explicit selections for this listing. The actual F20 or F21 application and supplied assembly still need confirmation.

Do I need extra sliders and side mounts with PCI?

PCI's standard S1 system includes its S1 sliders and SM-SIDE-S1 supports. Confirm the actual M140i listing's maker application, selected supports and seat interface before ordering. Extra generic sliders or supports should only be added where that assembly requires them.

Can I order the displayed RECARO 69.02 frame for an F21?

RECARO's F21 type 1K2 row specifies 69.03.19 and 69.03.29. The two displayed RECARO listings currently have 69.02-based choices. Ask us to confirm the correct F21 configuration and exact seat version before placing the order.

Does a RECARO frame accept every RECARO seat?

The application table has separate columns for particular seats and versions. Keep the exact seat label with the body and complete mounting configuration before choosing a Pole Position, Speed or Sportster combination.

Are the Monaco Pro and Sprint reclining seats?

They are fixed shells. Their current listings include base and side mounting options, which need checking against the actual seat revision. Choose the supports and lower assembly around those fixing points.

Do Sparco, Cobra and Corbeau seats share one base pattern?

The current listings show several patterns. Check the exact seat model and version against the runner or frame fixing points. A matching base pattern still does not establish vehicle-floor fit or cabin clearance.

Will a fitting frame lower the seat?

The installed position depends on the seat and the complete frame, runner and support assembly. We need that combination to assess the position and any measured height change.

Can I keep the standard belt or add a harness?

Check the actual seat, buckle arrangement and proposed restraint installation together. Use the restraint maker's current instructions and the correct anchorage arrangement for the selected equipment. A seat card or frame mounting tab does not settle that installation.

Does the F20 cage fit an F21?

The shop has separate F20 and F21 cage listings, so use the exact body and selected configuration when enquiring. Confirm installation parts, seat clearance and intended use with the maker.

What should I send with a fitting enquiry?

Send the body code, build details and physical side, plus the exact seat model or label. Include the product codes you are considering and whether you want sliding adjustment. Photos of the existing mounting area and proposed restraint details help us identify what needs checking.

Tell Garreth which F20 or F21 you have and the seat you want to use. Cameron can then work through the physical side and the frame, runner and support combination with you. Keep the exact product codes with the enquiry so the advice follows the parts being ordered.

Drop us an email or click to open a chat, or call 0115 647 8650. If you would like to try seats, contact us about a showroom visit with your car details. We can then discuss the seat choices alongside the fitting information you have.

Talk through your F20 or F21 fitting

Send your car details, physical side and exact seat model with the fitting parts you are considering.
