Saab Planted Technology Frames Updated For 2024

Seat frame news, June 2024

We have updated our Saab Planted Technology seat brackets with new products, fuller specifications and clearer descriptions of the cars they fit. Two new frames for the Saab 9-3 are now on the site, one for each generation.

Planted Technology are an American maker with one of the widest ranges of seat brackets and fitting parts available. Their frames suit seats from Recaro, Sparco, OMP, Corbeau, Cobra and many other brands.

  • Our Saab Planted Technology seat brackets updated for 2024
  • Two new frames for the Saab 9-3, one for each generation
  • First generation 9-3 (1998 to 2002): Planted part SB280
  • Second generation 9-3 (2003 to 2014): Planted part SB305
  • Each frame lines up with the factory floor mounts of its model
  • Keeps the car's original seat belt buckle in use
A stack of black Planted Technology seat frames on the showroom plinth, with labelled frames leaning against it
Planted Technology frames in our showroom, photographed in 2022. These are not Saab frames.

The new Saab 9-3 frames

The two new brackets cover both generations of the Saab 9-3, which are very different cars under one name. The first generation, from 1998 to 2002, is built on the older Saab 900 platform and takes part SB280. The second generation, from 2003 to 2014, moved to General Motors’ Epsilon platform and takes SB305. The first generation frame is handed, so order two for a pair of seats.

Each is designed by Planted Technology to line up with the factory bolt points in the floor of the 9-3, so fitting is quick, and each has plenty of bolt positions for most racing seats. Because the frames use the factory mounting points, the original seats come out whole, which is worth doing on a car whose interior parts are no longer made.

First generation 9-3

The SB280 bracket suits the 1998 to 2002 9-3, including the Viggen, Saab’s own performance version. A seat that holds you properly makes a real difference in a front wheel drive car with that much torque. Side airbags are fitted to these cars, so tell us the specification before anything comes out.

Second generation 9-3

The SB305 bracket suits the 2003 to 2014 9-3, including the Aero. Saab fitted side airbags widely across this generation too, so Garreth’s advice is to send us the car’s specification along with the seat you plan to fit, and we will check the frame, mounts and wiring all work together.

Why choose Planted Technology brackets

Planted brackets are laser cut and hand welded for an exact fit, and finished in black powder coat for corrosion resistance. The pre-slotted hole patterns take sliders from most major seat makers, including Bride, Cobra, Momo, OMP, Racetech, Recaro and Sparco, so a wide range of seats goes in without modification.

They can carry side mounts for a bucket seat, or the base of a reclining seat or base mounted bucket, with room for sliding runners between the frame and the seat. A model specific frame also keeps the car’s original seat belt buckle in use, which is why we recommend one wherever it is available.

Seat bolt patterns by brand

Base mounted seats bolt to the frame through a set pattern of four holes, and the pattern differs from brand to brand. That is why a frame made for one brand's seats does not always suit another's. Planted's slotted design is the exception, as it covers the common patterns.

Recaro seats use a wider pattern than most, which is one reason a Planted bracket is often the answer for a Recaro seat.

A grey Recaro seat on black sliding runners bolted to a black Planted Technology bracket on the floor of a silver car, seen through the open door
A Recaro seat on runners and a Planted Technology bracket.
Seat brandBase bolt pattern width
Corbeau345mm, or 291mm on some frames
Sparco345mm (345mm by 271mm)
OMP345mm
RecaroAbout 406mm

Side to side widths. Always check the pattern of your own seat before ordering a frame.

Planted frames in the showroom

We keep over 15 different Planted Technology base frames in the showroom, for a range of cars, ready to dispatch or collect, and for a limited time they all have a discount already applied. Their low design and many bolt points make them versatile, and we use them whenever a customer wants a precise fit.

Both 9-3 frames are in our Saab Planted Technology range, and across all makes we list over 300 Planted Technology frames, each named for the model it fits.

Part SB280 fits the 1998 to 2002 9-3. It is handed, so order two for a pair.

Part SB305 fits the 2003 to 2014 9-3.

Yes. The slotted patterns take sliders from most major brands, including Recaro.

Yes. A model specific frame lines up with the factory mounts and keeps the original buckle in use.

💬
New for 2024Planted frames for both 9-3s

Model specific brackets for the first and second generation Saab 9-3.
