Subaru Planted Technology Frames Updated For 2024

Seat frame news, July 2024

We have updated and expanded our Subaru Planted Technology seat brackets, with new products, fuller specifications and clearer descriptions of the cars they fit. There are now 18 Subaru frames on the site, seven of them new for 2024, covering popular models such as the Legacy, the Impreza and the BRZ.

Planted Technology are an American maker with one of the widest ranges of seat brackets and fitting parts available. Their frames suit seats from Recaro, Sparco, OMP, Corbeau, Cobra and many other brands, and each one is made for a specific car.

  • Our Subaru Planted Technology seat brackets updated for 2024
  • 18 Subaru frames on the site, seven of them new
  • New: the second generation BRZ and GR86, part SB392
  • New: the fifth generation Impreza, 2017 to 2023, part SB416
  • New: the VB chassis WRX from 2022, part SB401
  • Each frame lines up with the factory floor mounts of its model
A Subaru Impreza racing on track
A Subaru Impreza racing on track.

Seven new Subaru frames

The seven new brackets cover the latest Subarus and some older ones that were harder to find a bracket for. Each is designed by Planted Technology to line up with the factory bolt points in the floor, so fitting is quick, and each has plenty of bolt positions for most racing seats.

CarYearsPlanted part
BRZ and Toyota GR86, 2nd generation2021 onSB392
WRX, 2nd generation, VB chassis2022 onSB401
Impreza, 5th generation, GK and GT chassis2017 to 2023SB416
Crosstrek, 3rd generation, GU chassis2022 onSB415
Legacy, 2nd generation, BD, BG and BK chassis1993 to 1999SB385
Leone GL coupe, 3rd generation1984 to 1994SB402
Baja2003 to 2006SB261

The seven Subaru frames new to our range in 2024.

Two of these are worth a closer look. The second generation BRZ and GR86 are the same car built in the same factory, so one bracket covers both, while the first generation cars take the SB161 family. And the fifth generation Impreza is a separate car from the WRX of the same years, so if yours is turbocharged, SB416 is very likely not your bracket. Garreth’s advice is to send us the registration if you are unsure, and we will check it.

The rest of the Subaru range

Alongside the new frames, the range covers the Impreza, WRX and STI through the generations, from the 1993 to 2007 cars on SB019 to the 2015 on WRX and STI on SB206, plus the Legacy and Outback, the Forester, the XV Crosstrek, the SVX and the first generation BRZ.

Why choose Planted Technology brackets

Planted brackets are laser cut and hand welded for an exact fit, and finished in black powder coat for corrosion resistance. The pre-slotted hole patterns take sliders from most major seat makers, including Bride, Cobra, Momo, OMP, Racetech, Recaro and Sparco.

They can carry side mounts for a bucket seat, or the base of a reclining seat or base mounted bucket, with room for sliding runners between the frame and the seat. A model specific frame also keeps the car's original seat belt buckle in use.

A black Planted Technology seat bracket bolted to the floor of a BMW E39 5 Series, with the carpet and seat wiring beneath it
A Planted Technology bracket on the factory mounts of a customer's BMW. Not a Subaru.

Seat bolt patterns by brand

Base mounted seats bolt to the frame through a set pattern of four holes, and the pattern differs from brand to brand, which is why a frame made for one brand’s seats does not always suit another’s. Recaro and Corbeau seats are not interchangeable on the same frame, and Recaro’s wider pattern is why a Recaro seat goes on a Planted bracket.

Seat brandBase bolt pattern width
Corbeau345mm, or 291mm on some frames
Sparco345mm
OMP345mm
Recaro405mm, on Planted brackets

Side to side widths. Always check the pattern of your own seat before ordering a frame.

Planted frames in the showroom

We keep over 15 different Planted Technology base frames in the showroom, ready to dispatch or collect, and for a limited time they all have a discount already applied. All 18 Subaru frames are in our Subaru Planted Technology range, and across all makes we list over 300 Planted Technology frames.

Part SB392 fits the second generation BRZ and Toyota GR86 from 2021.

Not usually. The WRX of those years is a different car, so send us the registration to check.

Part SB401 fits the second generation WRX on the VB chassis from 2022.

Yes. A model specific frame lines up with the factory mounts and keeps the original buckle in use.

💬
New for 2024Seven new Subaru frames

From the Leone coupe to the latest WRX, a model specific Planted bracket.
