SW Motorsport Half Cage Kits Updated For 2025

Roll cage news, October 2024

Our range of SW Motorsports DIY half cage kits has been updated ready for the 2025 season, with a long list of new cars added over the last few weeks. Every kit now has its own listing with the specification and the options set out clearly.

These are kits for people who can build their own cage. They arrive unassembled, with the tubes already bent and notched, and they can be bolted in or welded in.

  • SW Motorsports DIY half cage kits updated for the 2025 season
  • Made from 45mm by 2.5mm CDS tube to the E355+N specification
  • That tube is what the Motorsport UK Blue Book asks for
  • Kits arrive unassembled, with the tubes bent and notched
  • Each kit can be bolted in or welded in, with optional braces and a harness bar
A red SW Motorsports half cage with cross bracing behind the front seats of a Volkswagen Golf, seen from the boot
A red SW Motorsports half cage fitted behind the front seats of a Golf.

What the SW half cage kits are

A half cage sits behind the front seats: a main hoop with backstays running to the rear of the car. It stiffens the shell, gives you protection behind you, and gives the shoulder straps of a harness proper mounting points, while the dashboard and front of the cabin stay as they are.

SW Motorsports design each kit for a specific car. The kits arrive unassembled, and all the tubes come bent and notched so they fit together with minimal gaps. They are made to be easy to assemble for anyone with welding and fabrication skills.

The tube and the Blue Book

Every kit is made from 45mm by 2.5mm CDS tube to the E355+N specification. That is the tube the Motorsport UK regulations, the Blue Book, set out for roll cages, so you start with the right material.

The kits are listed as Road and Track. How a cage is built and fitted matters as much as the tube, so if you are building for competition, check the regulations for your class before you start and have the finished cage looked at by your scrutineer.

A rendered drawing of a green SW Motorsports half cage kit with a hoop cross and a harness bar
A drawing of an SW Motorsports half cage kit with the hoop cross and harness bar options.

Bolt in or weld in, and the options

Each kit can be bolted in or welded in. Bolting in means the cage can come out again, which suits a car that is also used on the road. Welding in is permanent and gives the stiffest result.

You can then choose how the cage is braced. The options on each listing are a hoop cross, a rear cross, gussets for either, and a harness bar in the hoop. Garreth’s advice is to add the harness bar if you plan to run a harness at all: it is much easier to build it in now than to add it later.

Which cars are covered

The new kits cover a wide spread of cars, from small hatches like the Citroen Saxo, Peugeot 106 and 108, Suzuki Swift and Honda Jazz, to the Ford Focus Mk2, Honda Civic FK8, Mini F56, Audi A3, S3 and TT, BMW F21, E90 and G82 M4, Nissan 350Z and Porsche 928 and 944. There are more on the site, and the finished bolt-in half cages SW Motorsports make for other cars are listed alongside them.

You can see the whole range on our SW Motorsports roll cages page. If your car is not there, ask us what is available.

45mm by 2.5mm CDS tube to the E355+N specification, the tube set out in the Motorsport UK Blue Book.

No. They arrive unassembled, with the tubes bent and notched, ready for someone with welding and fabrication skills.

Yes. Each kit can be bolted in or welded in.

Yes. A hoop cross harness bar is one of the options on each kit, along with extra bracing and gussets.

💬
Worth addingThe harness bar

If a harness is ever likely, build the harness bar into the cage from the start.
