Safety Devices Morgan Roll Cages Updated For 2023

Roll cage news, May 2023

Our Safety Devices roll cages for Morgan have just been updated for 2023. The range covers several Morgan models, and every cage in it is a rear cage: it fits behind the seats only, which suits the open cockpit of a Morgan.

Each design has a few options, mainly whether the bar has a single diagonal or a cross diagonal, and every listing now sets those out clearly along with the colour choices. Here is what is in the range.

  • Safety Devices rear roll cages for Morgan, updated for 2023
  • Models include the Plus 4, Plus 8 and 4/4
  • Rear cages only, fitted behind the seats
  • Single diagonal or cross diagonal designs, some with a harness bar
  • Black powder coat as standard; grey, blue, silver, white or red to order
  • Each listing states whether the cage is homologated
A Safety Devices rear roll bar with a single diagonal, still wrapped in protective film, standing on a concrete floor in front of a roller shutter
A Safety Devices Morgan rear bar with a single diagonal, still wrapped for delivery.

The Morgan range

The Morgan cages are bolt-in rear bars, each made for a particular model, and the engine and chassis matter as much as the name. There is a bar for the two seat Plus 4 and 4/4 with the M16 engine, one for the Plus 8 and for the Plus 4 with the T16 engine on the Plus 8 chassis, a taller version of that bar with a cross diagonal and harness bars, one for the four seat 4/4, and one for the Plus 4 built from 2010 to 2020.

Most of these carry Motorsport UK and FIA homologation, but not all: the 2010 to 2020 Plus 4 cage and the plain rear bar with no diagonal are listed as not for competition use. Every listing states which is which, along with the Safety Devices part numbers.

Designs and colours

The choice on most Morgan bars is the bracing: a single fixed diagonal, or a cross diagonal. Some designs also add a harness bar, which gives a harness a proper mounting point, and the bars include bushes for the seat belt mounts. On the taller Plus 8 chassis bar there is also the option of universal door bars, which clamp to a tube in the front of the car.

Each cage can be bare metal or painted. Black powder coat is standard, with grey, blue, silver, white or red to order, and if you are after another colour, ask us and we will see what can be done.

Choosing the right bar

Morgans that look alike can need different bars, so the first job is to confirm the model, the number of seats, the engine and the chassis. Details like the door length, the door locks and inertia reels can matter too, and the listings say which versions each bar fits.

Garreth’s advice is to send us those details, and whether the car will be used for road, track days or competition, before ordering. Our guide to Safety Devices Morgan roll cages goes through the models in more depth, and our answer on a Morgan 4/4 two seater shows the questions we ask.

No. They are rear cages that fit behind the seats only.

Models including the Plus 4, Plus 8 and 4/4, with separate bars for different engines, chassis and seat layouts.

No. Most are, but some, such as the 2010 to 2020 Plus 4 cage, are not for competition use.

Black powder coat as standard, or grey, blue, silver, white or red, and unpainted by request.

💬
Start hereConfirm the chassis first

Engine, seats and chassis decide the bar, so check them before you order.
