OMP HTE-R Fibreglass FIA Motorsport Seat

From £586.80 Incl. VATFrom £489.00 Excl. VAT

FIA 8855-1999-homologated seat sized for a 36in to 38in or 32in to 36in waist. The showroom team sit in these seats every day, so call with your height and waist for the honest fit answer.

Seat Width

Clear

Perfect add-ons!

Choose any extras you would like added to this product.

OMP Low Profile Steel Side Mounts

£49.95

Endurance Motorsport Bucket Seat M8 Bolts Pack

Endurance Motorsport bucket seat M8 bolt pack

£3.45

TRS Magnum 6 Point FIA Harness Belt

Choose an option

£195.00

Add to wishlist

Size/Fitting guide

Save to Pinterest

The OMP HTE-R is a homologated fibreglass competition seat with an integrated head restraint. Part number OMPHA0-0772. Weight 9.4kg.

The head restraint and the width options

FIA 8855-1999, side mounted. The HTE-R carries a built-in padded head restraint, which the WRC-R and ARS-R do not. If you compete in a class or series that requires an integrated head restraint, this and the RS-PT 2 are the OMP fibreglass seats that satisfy it.

The HTE-R is also the seat with the widest size coverage across the OMP fibreglass range. It comes in two shell widths as a variation: Standard (32 to 36 inch waist) and Excel Width (36 to 38 inch waist). Tell us your waist measurement and we will confirm which to order.

How it compares to the RS-PT 2

Both have an integrated head restraint. The HTE-R uses Airtex trim; the RS-PT 2 uses velour. The HTE-R is 1kg lighter at 9.4kg against 10.4kg. The HTE-R covers a wider size band across both shell variants.

Construction

Gel-coated perforated fibreglass shell, Airtex trim throughout. High-profile side bolsters. Grip-textured dotted fabric on the seat cushion and shoulder contact areas. Removable split leg cushion. Adjustable lumbar. Five harness slots, 4, 5 and 6 point. HANS compatible.

What else you need

Seat only, no brackets. Side mounts sold separately at the standard 290mm competition spacing. Tell us the car and seat position and we will confirm the fitting list.

Additional information

Weight	9.4 kg
Dimensions	80 × 60 × 120 cm
Brand	OMP Racing
Seat Width	Excel Width, Standard
Construction	Fibreglass seats
Approval	FIA 8855-1999
Driver Height	All heights suitable
Driver Waist Size	36" – 38" Waist, 32" – 36" waist
Fixing Type	Side mount
Harness compatibility	4 point compatible, 6 point compatible
Product Colour	Black
Trim Material	Airtex
Mechanism Type	Fixed Back Seats
Protection Type	With head support
HANS Compatibility	HANS Friendly

OMP seat size guide

OMP publish a full dimension table for every shell, which makes them the easiest brand to size from a measurement. Most models are one size, with XL versions on the HTE-R, WRC-R, HRC-R and TRS-E.

How OMP size their seats

OMP quote external width at the shoulders, external width at the base, overall height and, the useful one, the inner width at the belt holes. Compare that inner width with your seated hip measurement: you want 20 to 40 mm of room, no more. The XL shells add 20 to 45 mm of inner width and 30 to 60 mm of height.

The HTE-R is the mid-size shell at 390 mm inside; the HTE-R XL and WRC-R XL go to 415 mm; the TRS-E XS is the slim one at 330 mm. Carbon versions of the same model are a little narrower than the fibreglass ones, which is worth knowing if you are at the edge.

OMP dimensions

From OMP’s race seat size guide. All figures in mm; weight is the complete seat, plus or minus 10 percent.

Model	Shoulder width	Base width	Height	Inner width	Weight
Fibreglass
HTE-R	560	515	880	390	9.4 kg
HTE-R 400	560	515	880	390	10.2 kg
HTE-R XL	580	530	920	415	10.5 kg
HRC-R Fibreglass Air	620	470	900	365	9.5 kg
HRC-R Fibreglass Air XL	610	490	980	400	10.3 kg
WRC-R	620	510	890	390	8.8 kg
WRC-R XL	665	520	920	415	10.7 kg
ARS-R	590	500	910	370	8.9 kg
RS-P.T.2	565	510	880	395	10.4 kg
Champ R	590	520	890	360	8.8 kg
First-R	620	510	890	390	8.9 kg
Carbon
HTE-R Carbon	545	465	880	370	6.6 kg
HTE-R Carbon XL	560	485	890	390	6.8 kg
HRC-R Carbon	615	460	890	365	5.8 kg
HRC-R Carbon Air	615	460	890	365	6.2 kg
HRC-ONE	615	455	900	365	9.2 kg
WRC-R Carbon	590	495	890	365	5.6 kg
ARS-R Carbon	585	480	890	360	5.8 kg
Tubular steel
TRS-E, TRS-E Plus, TRS-E Sky	585	510	890	390	10.3 to 10.8 kg
TRS-E XS	520	420	870	330	10.2 kg
TRS-E XL	625	540	950	415	12.3 kg

Which OMP fits you

Model	Waist band	Driver height	Shell	Approval
Competition, FIA
HTE R	Standard 32 to 36 / Excel 36 to 38	All heights	Fibreglass or carbon	FIA 8855-1999
HTE R 400	32 to 36	All heights	Fibreglass	FIA 8855-1999
HTE EVO, HTE EVO VTR, HTC EVO VTR	36 to 38	All heights	Fibreglass	FIA 8855-1999 / 8855-2021 (VTR)
HGT / HGT Evo	36 to 38	All heights	Carbon / fibreglass	FIA 8855-1999 / 8855-2021
HRC R, HRC R Air	32 to 36 carbon, 36 to 38 fibreglass	All heights	Carbon or fibreglass	FIA 8855-1999
HRC One	36 to 38	All heights	Carbon	FIA 8862-2009
WRC R	32 to 36	Under 6 ft	Fibreglass	FIA 8855-1999
WRC R XL	36 to 42	Under and over 6 ft	Fibreglass	FIA 8855-1999
ARS, ARS R	36 to 38	All heights	Fibreglass	FIA 8855-1999
RS PT 2, Champ R	32 to 36	Under 6 ft	Fibreglass	FIA 8855-1999
First R	32 to 38	Under 6 ft	Fibreglass	FIA 8855-1999
RT	32 to 36	All heights	Fibreglass or carbon	FIA 8855-1999
TRS E Sky	28 to 36	Under 6 ft	Tubular steel	FIA 8855-1999
Road and track
HTE EVO Off	32 to 36	All heights	Fibreglass	Road and track
Classic
1970s Revival, Brands Hatch, Silverstone	All sizes	All heights	Steel frame	Road and track

The WRC-R XL is the big oneAt 665 mm across the shoulders and 415 mm inside it is the widest OMP we list, and the only one we band to a 42 inch waist.

Every OMP shell in the table fixes through the side with four M8 8.8 bolts as a minimum. The TRS-E also takes bottom fixing.

Measure yourself first

Four numbers decide whether a seat fits. Take them in the clothes you drive in, and write them down before you compare models.

AWaistAround your natural waist, not your trouser size. Trouser sizes usually run an inch or two under the real figure, and the waist bands on our product pages use the real one.

BSeated hip widthSit on a hard chair with your feet flat and measure straight across the widest point of your hips with a rule or a straight edge, not a tape that follows the curve. This is the number that decides whether a fixed shell is tight.

CShouldersStraight across the back at the widest point. Fixed back seats hold you here, so a shell that is narrow at the shoulders is uncomfortable long before it is unsafe.

DHeight and torsoYour height, and if you are over 6 ft whether that is mostly leg or mostly body. A long body needs a taller shell with the head support set higher.

Before you order

Check the car, not only the driver. Transmission tunnels, door cards and B pillars are what stop a wide shell going in. Our seat mounting and fixing points guide covers what to measure.
Side mount and base mount shells are not interchangeable. Which one you need depends on the car and the subframe, so pick the brackets at the same time as the seat.
If you run a HANS or plan to, filter on HANS friendly. The shoulder openings are cut to clear the collar.
FIA seats carry an expiry date on the homologation label. Check what your championship accepts and how long the seat has left, particularly on discounted older stock.

Send us your measurementsWaist, seated hip width, height and the car. We have fitted a lot of OMP seats and will tell you honestly if the one you have picked is going to be tight. Call 0115 989 3488 or email Sales@GSMPerformance.co.uk.

Waist bands and heights are our product data, checked 6 September 2026. Dimensions and weights are from OMP’s race seat size guide.

Have you written anything about this exact product?
Yes, we have covered this exact product: OMP HTE-R 400 FIA Motorsport Seat Now on Display, and OMP HTE R 400 Fibreglass FIA Motorsport Seat A Closer Look From Our Showroom. That is first-hand coverage from our own builds and showroom, not brochure copy.

Will I fit in this seat?
The maker sizes this seat for drivers with a 36in to 38in or 32in to 36in waist. Those are the paper numbers; how a seat actually feels to sit in and climb out of is a different question, and our showroom team sit in these seats every day, so call us with your height and waist and we will give you the honest answer.

Is it FIA approved, and for how long?
Yes, it carries FIA 8855-1999 homologation. Every FIA seat has a not-valid-after year printed on its homologation label, and that label date is what a scrutineer checks, so look at the label on the seat you receive and check it against your championship regulations. Buying new means you get the freshest label the maker currently produces.

What do I need to fit it to my car?
This is a side-mount seat: it hangs between side brackets, the motorsport-style stack with fine height and angle control. You will need the car-specific frame, and a sliding runner if you want fore-and-aft adjustment. Our guide on base mount versus side mount walks through the whole stack, and tell us your car and we will quote the full kit.

Does it work with harnesses and a HANS device?
The shell takes 4 point compatible and 6 point compatible. If you are planning the full seat, harness, and HANS setup, tell us the car and we will spec it end to end.

How do I know it will feel right, not just fit on paper?
Fair question, because makers publish widths and weights, never feel, and two seats with identical numbers can feel nothing alike in the car. We keep the ranges on display in the Nottingham showroom, you are welcome to come and sit in them, and if you cannot get to us, call and describe your build, as the team sit in these seats every day. Our head support measurements guide shows the kind of real-world data we collect.
