Hundreds Of Products Ready Today. Dispatch/Collection Corbeau bucket seat brackets, what fits what
Subframes and runners
Corbeau are the interesting one on brackets, because their runner is the closest thing to a universal part that anybody makes. It comes in four handle widths on a single listing, 291mm, 345mm, 370mm and 405mm, and between them those cover every base mount pattern in the market including Cobra at one end and Recaro at the other.
The old version of this page said Corbeau were a 345mm brand. That is one of the four widths, not the answer. Which one you need is set by the seat range, and the listing spells it out, so this is a question you can settle in a minute rather than guess at.
- 152 Corbeau frames live, covering car and seating side
- Four runner handle widths: 291mm, 345mm, 370mm and 405mm
- Frames run £180 to £289.50, with most at a flat £245
- Base mounted seats only, there is no Corbeau side mount route
- Frames are priced for one seat, so a pair is two of them
The two parts you need
Corbeau is simpler than the other three brands on this site, because Corbeau frames are for base mounted seats and there is no Corbeau side mount. That leaves two parts rather than three.
The subframe
undefined
The runner
undefined
Four handle widths, and which seats take each
This is the part the old page had wrong and it is the most useful thing here. Corbeau publish four handle widths on one runner product and map each to a named seat range. Straight off the listing:
| Handle width | Corbeau range | What else it suits |
|---|---|---|
| 291mm | Sportline and Classic seats | Corbeau and Cobra base mounted seats on a 291mm pattern |
| 345mm | Standard width Motorsport seats | A range of base mounted seats including Corbeau, Sparco and OMP |
| 370mm | L width Motorsport seats | Side mounted Motorsport seats, depending on shell width |
| 405mm | XL width Motorsport seats | Recaro seats and wide tracked Motorsport seats on side mounts |
From the Corbeau Seat Sliding Runners listing, product 15739. You pick the handle on the drop-down when you order. This is the only runner on the site that carries all four, which is why it turns up in builds that have nothing to do with Corbeau seats.
| Seat brand | Base mount bolt pattern | The part that proves it |
|---|---|---|
| Sparco | 345mm | Sparco Seat Sliding Runner Kit, 14036 |
| OMP | 345mm | OMP Seat Slider And Runner Kit, 15620 |
| Sabelt | 345mm | Sabelt Seat Sliding Runner Kit, 123871 |
| Corbeau | 291mm, 345mm, 370mm or 405mm | Corbeau Seat Sliding Runners, 15739 |
| Cobra | 291mm, or 405mm on the motorsport shells | Cobra Premium Sliding Runners, 120664 |
| Recaro | 405mm | Recaro Double Locking Sliding Runners, 14037 |
Read this as the width across the two rails, measured between the bolt centres. Sparco, OMP and Sabelt all sit on 345mm, which is why one runner kit carries all three. Corbeau publish four handle widths on a single product and Cobra publish two, so those are the two to check rather than assume. Corbeau are the row that overlaps every other row, which is the whole point of the four handle options.
The two mounting interfaces, drawn to scale
Side mount
Base mount
Side mount fixings sit at roughly 290mm front to rear. Base mount patterns are measured across the car. Corbeau frames are for the base mount side of this drawing.
The frame is Corbeau only. The runner is not.
Our listing on 166 of the 171 Corbeau frames says they fit seats of the same brand and that fitment is not guaranteed with anything else. That is Corbeau’s position on the frames and we will not argue with it on a page people order from.
The runner listing is the opposite, and it is unusually open about it. It says the runners suit all seats in the Corbeau range, then adds in brackets that other seats will fit and to contact us for advice. None of the other three brands invite that. Combined with the four handle widths, it is why the Corbeau runner ends up under seats from half a dozen other makers.
What a pair of seats actually costs
Corbeau frames are priced for one frame, which fits one seat. So is the runner. Corbeau are the most expensive of the four brands here by a distance, with a median frame price of £245 against £72.50 for Sparco, so the count matters more than it does elsewhere.
A worked example on the Golf Mk7, two base mounted Corbeau seats:
| Part | Quantity | Price each | Line total |
|---|---|---|---|
| Golf Mk7 direct fit subframe, 19215 | 2, one per side | £245.00 | £490.00 |
| Corbeau sliding runner, 15739 | 2, if not already in the kit | £49.00 | £98.00 |
| or the 345mm pair kit instead, 184690 | 1 kit covering 2 seats | £98.00 | £98.00 |
Check the frame options before adding runners, because some Corbeau kits already include them and the listing says so. The pair kits come in all three of the common widths, 291mm as 214839, 345mm as 184690 and 405mm as 214840, all at £98.
Check the options before you add a runner
Corbeau frames vary. Some are a complete replacement frame, some are runners and brackets, and some are adaption bars that bolt to what is already in the car. The listing notes which in the options and the price. Read that before you add a separate runner, or you will end up with a spare set.
If you are buying a frame without a seat, put the seat model in the comments box at checkout so we can check the pair before it ships.
The frames people buy most
The Corbeau subframes that leave here most often. There are 152 live, so search or ring us if your car is not among them.
-
From £289.50 Excl. VAT Select options This product has multiple variants. The options may be chosen on the product page
-
From £245.00 Excl. VAT Select options This product has multiple variants. The options may be chosen on the product page
Runners
The single runner is where the four handle widths live. Pick the width on the drop-down, and if you are not certain which range your seat belongs to, ring us rather than guess.
Each one fits a single seat. If you are doing both sides, the pair kits work out at the same money as two singles and save you a line on the order.
Check your frame first. Some Corbeau kits already include the runners.
-
From £49.00 Excl. VAT Select options This product has multiple variants. The options may be chosen on the product page
If your car is not on the list
Corbeau cover the mainstream European cars and a decent spread of classics, the Beetle among them. When there is no Corbeau frame, universal adaption bars are the usual answer and the Endurance bars carry 291mm, 345mm and 405mm on one part, so they line up with three of the four Corbeau handle widths.
Planted are the other route and cover a lot of Japanese and American cars that the European catalogues skip.
-
From £32.50 Excl. VAT Select options This product has multiple variants. The options may be chosen on the product page
Before you order
- Is your seat base mounted? Corbeau frames will not take a side mounted shell.
- Which handle width? 291mm for Sportline and Classic, 345mm for standard Motorsport, 370mm for L width, 405mm for XL.
- Does the frame already include runners? The options and price say so. Check before adding them.
- How many frames? They are priced per seat, so a pair of seats is two frames.
- Doing both sides? The pair runner kits save a line and cost the same.
- Buying the frame without the seat? Put the seat model in the checkout comments.
Common questions
What is the Corbeau bolt pattern?
There are four, and that is the useful bit. 291mm on the Sportline and Classic seats, 345mm on the standard width Motorsport seats, 370mm on the L width and 405mm on the XL width. You pick the matching handle when you order the runner.
Do Corbeau frames come with the sliding runners?
Sometimes. Some kits are a complete replacement frame, some are runners and brackets, and some are adaption bars. The options and the price on each listing tell you which. Read that before you add a separate runner.
Will a Corbeau subframe fit a Sparco or OMP seat?
Corbeau say no on the frames, and our listing repeats it on 166 of the 171. The runner is a different matter and the 345mm handle is listed as suitable for Corbeau, Sparco and OMP base mounted seats. Ring us with the seat and the car if you want it checked.
Can I use a Corbeau runner under a Cobra seat?
The 291mm handle is listed as suitable for Corbeau and Cobra base mounted seats on a 291mm pattern, so yes on the face of it, and it is cheaper than the Cobra part. Give us a ring before you order, because Cobra specify their own runner for their subframe applications.
Can I use side mounted seats with a Corbeau frame?
No. Corbeau frames are for base mounted bucket seats and reclining sport seats. There is no Corbeau side mount either, so a side mounted shell needs a universal set of side mounts and a frame to suit.
Why are Corbeau frames more expensive than the others?
They are the dearest of the four brands here, mostly a flat £245 against a £72.50 median on Sparco and £102.92 on OMP. That is what Corbeau charge for them. If budget is the driver and your car is covered by more than one brand, the Sparco or OMP frame will do the same job for less, provided you are running their seat.
Is the price for one frame or a pair?
One, and it fits one seat. If you want both sides, add it twice and pick a different seating position each time.
There is no Corbeau frame for my car. What now?
Universal adaption bars are the usual answer and the Endurance bars carry 291mm, 345mm and 405mm on one part. Planted are the other option and cover a lot of Japanese and American cars. Ring us with the car and we will tell you which is sensible.
